Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 54 —
* 1-667-387-11 HP BOARD
*********
< CAPACITOR >
C491 1-162-294-31 CERAMIC 0.001uF 10% 50V
C591 1-162-294-31 CERAMIC 0.001uF 10% 50V
< JACK >
J660 1-764-106-21 JACK (PHONES)
************************************************************
* 1-653-379-51 MOTOR BOARD
*************
< JACK >
CNJ303 1-770-348-21 CONNECTOR, FPC 7P
< SWITCH >
S301 1-571-754-31 SWITCH, PUSH (1 KEY)
************************************************************
* A-4403-540-A PANEL BOARD, COMPLETE (SP,MY,HK,JE)
**********************
* A-4403-560-A PANEL BOARD, COMPLETE (AEP,G)
**********************
* A-4403-727-A PANEL BOARD, COMPLETE (UK)
**********************
* 4-932-810-11 CUSHION (FL)
* 4-994-815-01 HOLDER (FL)
< CAPACITOR >
C701 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C702 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C703 1-126-157-11 ELECT 10uF 20% 16V
C704 1-124-584-00 ELECT 100uF 20% 10V
C705 1-104-905-11 CAPACITOR 0.22F 5.5V
C706 1-126-157-11 ELECT 10uF 20% 16V
C707 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C708 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C709 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C710 1-101-004-00 CERAMIC 0.01uF 50V
C711 1-102-958-00 CERAMIC 20PF 5% 50V
C712 1-102-958-00 CERAMIC 20PF 5% 50V
C713 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C715 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C716 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C717 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C718 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C719 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C720 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C721 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C722 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C723 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C724 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C725 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C726 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C727 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C728 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C729 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C730 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C731 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C751 1-126-154-11 ELECT 47uF 20% 6.3V
C752 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
* CN701 1-568-842-11 SOCKET, CONNECTOR 27P
CN702 1-779-970-11 PLUG, CONNECTOR
CN703 1-779-938-11 CONNECTOR, BOARD TO BOARD 8P
CN752 1-580-918-11 HOUSING, CONNECTOR 5P
< DIODE >
D701 8-719-016-74 DIODE 1SS352
D702 8-719-016-74 DIODE 1SS352
D703 8-719-210-33 DIODE EC10DS2
D704 8-719-210-33 DIODE EC10DS2
< FILTER >
FL701 1-517-701-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 8-759-481-03 IC uPD780206GF-023-3BA
IC751 8-759-459-84 IC NJL56H400 (REMOTE SENSOR)
IC850 8-759-165-80 IC PST600C-T
< COIL >
L701 1-412-344-41 INDUCTOR 22uH
< TRANSISTOR >
Q701 8-729-424-59 TRANSISTOR UN2212
Q704 8-729-421-22 TRANSISTOR UN2211
< RESISTOR >
R701 1-216-073-00 METAL CHIP 10K 5% 1/10W
R702 1-216-073-00 METAL CHIP 10K 5% 1/10W
R704 1-216-073-00 METAL CHIP 10K 5% 1/10W
R706 1-216-025-91 METAL GLAZE 100 5% 1/10W
R707 1-216-029-00 METAL CHIP 150 5% 1/10W
R708 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R709 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R710 1-216-025-91 METAL GLAZE 100 5% 1/10W
R711 1-216-025-91 METAL GLAZE 100 5% 1/10W
R712 1-216-025-91 METAL GLAZE 100 5% 1/10W
R713 1-216-025-91 METAL GLAZE 100 5% 1/10W
R714 1-216-025-91 METAL GLAZE 100 5% 1/10W
R715 1-216-025-91 METAL GLAZE 100 5% 1/10W
R716 1-216-025-91 METAL GLAZE 100 5% 1/10W
R717 1-216-025-91 METAL GLAZE 100 5% 1/10W
R718 1-216-025-91 METAL GLAZE 100 5% 1/10W
R719 1-216-025-91 METAL GLAZE 100 5% 1/10W
R720 1-216-025-91 METAL GLAZE 100 5% 1/10W
R721 1-216-017-91 METAL GLAZE 47 5% 1/10W
R722 1-216-017-91 METAL GLAZE 47 5% 1/10W
HP MOTOR PANEL
