Sony HCD-BX5 - Electrical Parts Lists - Various Sections; Parts Lists for BD, Driver, Head, Main Sections

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51
< RESISTOR >
R101 1-216-077-91 RES-CHIP 15K 5% 1/10W
R102 1-216-097-91 RES-CHIP 100K 5% 1/10W
R103 1-216-077-91 RES-CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-073-00 METAL CHIP 10K 5% 1/10W
R106 1-216-049-91 RES-CHIP 1K 5% 1/10W
R107 1-216-073-00 METAL CHIP 10K 5% 1/10W
R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R109 1-216-121-91 RES-CHIP 1M 5% 1/10W
R110 1-216-025-91 RES-CHIP 100 5% 1/10W
R111 1-216-121-91 RES-CHIP 1M 5% 1/10W
R113 1-216-121-91 RES-CHIP 1M 5% 1/10W
R114 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-049-91 RES-CHIP 1K 5% 1/10W
R118 1-216-025-91 RES-CHIP 100 5% 1/10W
R119 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-91 RES-CHIP 100K 5% 1/10W
R131 1-216-033-00 METAL CHIP 220 5% 1/10W
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R147 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES-CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-91 RES-CHIP 15K 5% 1/10W
R181 1-216-078-00 RES-CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-91 RES-CHIP 15K 5% 1/10W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT IN)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL(16.9344 MHz )
**************************************************************
1-675-912-11 DRIVER BOARD
************
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-983-63 DIODE MTZJ-T-72-3.3B
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-676-220-11 HEAD(A) BOARD
*************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
1-676-221-11 HEAD(B) BOARD
*************
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
A-4428-070-A MAIN BOARD, COMPLETE (AED,AEP,CIS,G,UK)
*********************
A-4428-084-A MAIN BOARD, COMPLETE (CND,US)
*********************
A-4428-090-A MAIN BOARD, COMPLETE (MY,SP,TW)
*********************
A-4428-288-A MAIN BOARD, COMPLETE (EA)
*********************
A-4428-290-A MAIN BOARD, COMPLETE (AUS)
*********************
A-4428-292-A MAIN BOARD, COMPLETE (E)
*********************
A-4428-735-A MAIN BOARD, COMPLETE (AR,MX)
*********************
A-4428-910-A MAIN BOARD, COMPLETE (TH)
*********************
A-4428-958-A MAIN BOARD, COMPLETE (KR)
*********************
4-224-796-21 HEATSINK (B)
7-685-646-79 SCREW+BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C102 1-126-961-11 ELECT 2.2uF 20.00% 50V
C103 1-126-964-11 ELECT 10uF 20.00% 50V
C104 1-126-964-11 ELECT 10uF 20.00% 50V
C105 1-126-964-11 ELECT 10uF 20.00% 50V
C106 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C107 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C108 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C109 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C110 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
BD DRIVER HEAD (A) HEAD (B) MAIN
