50
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•Abbreviation
CND : Canadian model
AUS: Australian model
G: German model
AED : North European model
EA : Saudi Arabia model
MY : Malaysia model
SP : Singapore model
TH : Thai model
TW : Taiwan model
KR : Korea model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
MX : Mexican model
AR : Argentina model
1-675-911-11 ADDRESS SENSOR BOARD
**********************
< IC >
IC711 8-749-016-76 IC RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY)(UP DOWN)
**************************************************************
A-4724-934-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C104 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C110 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C111 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C112 1-107-682-11 CERAMIC CHIP 1uF 10.00% 16V
C114 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C115 1-104-665-11 ELECT 100uF 20.00% 10V
C116 1-104-665-11 ELECT 100uF 20.00% 10V
C117 1-104-665-11 ELECT 100uF 20.00% 10V
C118 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C119 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C121 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C122 1-104-665-11 ELECT 100uF 20.00% 10V
C123 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C124 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C125 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C126 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C127 1-104-665-11 ELECT 100uF 20.00% 10V
C129 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C130 1-164-346-11 CERAMIC CHIP 1uF 16V
C131 1-126-964-11 ELECT 10uF 20.00% 50V
C133 1-164-346-11 CERAMIC CHIP 1uF 16V
C140 1-164-346-11 CERAMIC CHIP 1uF 16V
C141 1-164-346-11 CERAMIC CHIP 1uF 16V
C143 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C145 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C153 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C162 1-104-665-11 ELECT 100uF 20.00% 10V
C163 1-104-665-11 ELECT 100uF 20.00% 10V
C165 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C167 1-163-237-11 CERAMIC CHIP 27PF 5.00% 50V
C168 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C171 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C172 1-163-123-00 CERAMIC CHIP 180PF 5% 50V
C181 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C182 1-163-123-00 CERAMIC CHIP 180PF 5% 50V
< CONNECTOR >
CN101 1-784-741-11 CONNECTOR, FFC 19P
CN102 1-793-907-11 CONNECTOR, FFC/FPC 16P
< FERRITE BEAD >
FB101 1-500-445-21 FERRITE 0UH
FB103 1-500-445-21 FERRITE 0UH
< IC >
IC101 8-752-386-85 IC CXD2587Q
IC102 8-759-549-28 IC BA5974FP-E2
IC103 8-752-085-51 IC CXA2568M-T6
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710-RTX
ADDRESS SENSOR BD
To Next Page
