Sony HCD-CP101 - Page 19

HCD-CP101
1919
3.7 Vp-p
230 ns
13.6 Vp-p
18.4 µs
67.2 Vp-p
18.4 µs
6 IC101 w; (SCOR) (CD Play Mode)
Approx.
200 mVp-p
•Waveforms
– CD Board –
1 IC103 qh (RFO) (CD Play Mode)
2 IC103 qf (FE) (CD Play Mode)
3 IC103 qd (TE) (CD Play Mode)
4 IC101 qg (WFCK)
5 IC101 qj (XPCK)
7 IC101 yh (XTAI) qs Q401 Collector (REC Mode)
1.2 ±0.1 Vp-p
Approx.
380 mVp-p
5.1 Vp-p
136 µs
5.9 Vp-p
230 ns
13.2 ms
5 V
3 Vp-p
16.9344 MHz
– TC Board –
qa T401 (REC Mode)
– MAIN Board –
wa IC804 qf (XO) (AEP, UK only)
ws IC801 r; (XTAL1)
qd T101, 201 (REC Mode) wd IC801 os (TX)
5.2 Vp-p
236 ns
57.6 Vp-p
18.4 µs
5.1 Vp-p
30.6 µs
