Sony HCD-CP101 - Front Panel Section; Tape Mechanism Deck

HCD-CP101
9
3-4. FRONT PANEL SECTION
3-5. TAPE MECHANISM DECK
1 wire (flat type) 18p
(CN802)
1 wire (flat type) 20p
(CN804)
1 wire (flat type) 23p
(CN801)
2 connector
(CN501)
3 two screws
(BTP3
× 8)
4 screw (KTP3 × 6)
4 screw (KTP3 × 6)
1 wire (flat type) 17p
(CN301)
5 front panel section
2 three screws
(BVTT2.6
× 5
)
6 two screws
(BTP3
× 8)
6 two screws
(BTP3
× 8)
7 tape machanism deck
5 TC board
1 wire flat type 8P
(CN302)
4 connector
(CNP1)
3
