Sony HCD-CP101 - CONTROL AND INDICATOR SECTIONS; Control Board Printed Wiring

HCD-CP101
2828
6-13. PRINTED WIRING BOARDS – CONTROL Section – • See page 18 for Circuit Boards Location.
CONTROL (A) BOARD
1-683-887-
IC802
CONTROL (B) BOARD
1-683-888-
11
(11)
D854, 855, S809
REC
CD SYNC
TAPE
21
(21)
(US, CND, MX)
BAND
D856, 857, S816
+
−
TUNING
TUNER
TUNING
MODE
2
CD
D852, 853, S802
PLAY MODEREPEAT
C
MAIN BOARD
CN801
VOLUME
ROTARY
ENCODER
ROTARY
ENCODER
ROTARY
ENCODER
31
DSG
D858, S817
FUNCTION
TREBLE
13
BASS
13
STANDBY
11
(11)
21
(21)
EXCEPT
US, CND, MX
(US, CND, MX)
CD INDICATOR BOARD
1-683-893-
2
D860, 861, 863
(CD TRAY ILLUMINATION)
11
(11)
21
(21)
EXCEPT
US, CND, MX
(US, CND, MX)
A
B
C
D
E
F
1 2 3 4 5 6 7 8 9 10
1
3
EXCEPT
US, CND, MX
D851 A-9
D852 E-3
D853 F-4
D854 B-1
D855 B-2
D856 B-4
D857 A-4
D858 A-7
D859 C-1
D860 E-7
D861 E-7
D863 E-7
IC802 C-7
Q851 A-9
Q852 C-4
Q853 B-2
Q854 B-4
Q855 A-7
Q856 A-4
Q857 A-9
Ref. No. LocationRef. No. Location
• Semiconductor Location
(Page 24)
Ver 1.2
