Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
43
HCD-CP101
R675 1-216-833-11 METAL CHIP 10K 5% 1/10W
R676 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R677 1-216-818-11 METAL CHIP 560 5% 1/10W
R679 1-216-815-11 METAL CHIP 330 5% 1/10W
R684 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R685 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R686 1-216-821-11 METAL CHIP 1K 5% 1/10W
R687 1-216-816-11 METAL CHIP 390 5% 1/10W
R689 1-216-841-11 METAL CHIP 47K 5% 1/10W
R690 1-216-837-11 METAL CHIP 22K 5% 1/10W
R691 1-216-833-11 METAL CHIP 10K 5% 1/10W
R692 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R698 1-216-816-11 METAL CHIP 390 5% 1/10W
< ROTARY ENCODER >
RV801 1-473-392-11 ENCODER, ROTARY (VOLUME)
RV802 1-418-859-11 ENCODER, ROTARY (TREBLE)
RV803 1-418-859-11 ENCODER, ROTARY (BASS)
< SWITCH >
S801 1-786-220-11 SWITCH, KEY BOARD (I/1)
S802 1-786-220-11 SWITCH, KEY BOARD (H S)
S803 1-786-220-11 SWITCH, KEY BOARD (s)
S804 1-786-220-11 SWITCH, KEY BOARD (M >)
S805 1-786-220-11 SWITCH, KEY BOARD (m .)
S806 1-786-220-11 SWITCH, KEY BOARD (PLAY MODE)
S807 1-786-220-11 SWITCH, KEY BOARD (REPEAT)
S808 1-786-220-11 SWITCH, KEY BOARD (Z)
S816 1-786-220-11 SWITCH, KEY BOARD (BAND)
S817 1-786-220-11 SWITCH, KEY BOARD (DSG)
S818 1-786-220-11 SWITCH, KEY BOARD (TUNING +)
S819 1-786-220-11 SWITCH, KEY BOARD (TUNING –)
S820 1-786-220-11 SWITCH, KEY BOARD (TUNING MODE)
S821 1-786-220-11 SWITCH, KEY BOARD (FUNCTION)
**************************************************************
A-4728-262-A CONTROL (B) BOARD, COMPLETE
(AEP, UK, E, SP, AR, AUS)
A-4729-394-A CONTROL (B) BOARD, COMPLETE
(US, CND, MX)
A-4730-024-A CONTROL (B) BOARD, COMPLETE (KR)
****************************
< LED >
D854 6-500-076-01 LED SLI-343YC (h H)
D855 6-500-076-01 LED SLI-343YC (h H)
D859 8-719-074-42 LED SLR325VR-T31 (CD SYNC)
< TRANSISTOR >
Q853 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R660 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R661 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R662 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R663 1-216-833-11 METAL CHIP 10K 5% 1/10W
R664 1-216-837-11 METAL CHIP 22K 5% 1/10W
R665 1-216-841-11 METAL CHIP 47K 5% 1/10W
R666 1-216-821-11 METAL CHIP 1K 5% 1/10W
R680 1-216-820-11 METAL CHIP 820 5% 1/10W
R697 1-216-816-11 METAL CHIP 390 5% 1/10W
< SWITCH >
S809 1-786-220-11 SWITCH, KEY BOARD (h H)
S810 1-786-220-11 SWITCH, KEY BOARD (s)
S811 1-786-220-11 SWITCH, KEY BOARD (M)
S812 1-786-220-11 SWITCH, KEY BOARD (m)
S813 1-786-220-11 SWITCH, KEY BOARD (X)
S814 1-786-220-11 SWITCH, KEY BOARD (z REC)
S815 1-786-220-11 SWITCH, KEY BOARD (CD SYNC)
**************************************************************
1-683-891-11 HEADPHONE BOARD
(AEP, UK, E, SP, AR, KR, AUS)
1-683-891-21 HEADPHONE BOARD (US, CND, MX)
*****************
< CAPACITOR >
C161 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C261 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< FERRITE BEAD >
FB101 1-414-813-11 FERRITE 0uH (US, CND, MX)
FB201 1-414-813-11 FERRITE 0uH (US, CND, MX)
FB303 1-414-813-11 FERRITE 0uH (US, CND, MX)
< JACK >
J301 1-794-453-11 JACK (PHONES)
< COIL >
L102 1-412-002-31 INDUCTOR 4.7uH
L202 1-412-002-31 INDUCTOR 4.7uH
L307 1-410-997-42 INDUCTOR 2.2uH (US, CND, MX)
**************************************************************
1-683-890-11 LCD BOARD (AEP, UK, E, SP, AR, KR, AUS)
1-683-890-21 LCD BOARD (US, CND, MX)
**********
< CONNECTOR >
CN803 1-785-952-11 CONNECTOR, FFC/FPC (ZIF) 20P
CN810 1-785-951-11 CONNECTOR, FFC/FPC (ZIF) 18P
< LED >
D866 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
D867 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
D868 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
D869 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-542-21 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R627 1-249-407-11 CARBON 150 5% 1/4W
R628 1-249-407-11 CARBON 150 5% 1/4W
**************************************************************
CONTROL (A) CONTROL (B) HEADPHONE LCD
Ver 1.2
