Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
63
HCD-CPX1
< TRANSISTOR >
Q990 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
(SP, KR, AUS)
Q991 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
< RESISTOR >
R991 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R992 1-216-845-11 METAL CHIP 100K 5% 1/10W
R993 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(SP, KR, AUS)
R994 1-216-845-11 METAL CHIP 100K 5% 1/10W
(SP, KR, AUS)
< RELAY >
0RY990 1-755-467-11 RELAY (POWER) (SP, KR, AUS)
0RY991 1-755-467-11 RELAY (POWER)
< TRANSFORMER >
0T991 1-437-675-11 TRANSFORMER, POWER (US, CND)
0T991 1-437-677-11 TRANSFORMER, POWER (SP, KR, AUS)
**************************************************************
A-4731-306-A SWITCH BOARD, COMPLETE
***********************
< CAPACITOR >
C807 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C808 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C809 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C810 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C811 1-126-947-11 ELECT 47uF 20% 10V
C812 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C813 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C814 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C815 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C816 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN801 1-784-780-11 CONNECTOR, FFC 19P
< LED >
D801 8-719-812-44 LED TL0124 (STANDBY)
D802 8-719-046-36 LED SEL5921A-TP15 (DSG)
D803 8-719-046-36 LED SEL5921A-TP15 (CD NX)
D804 8-719-046-36 LED SEL5921A-TP15 (TUNER BAND)
D805 8-719-046-36 LED SEL5921A-TP15 (TAPE nN)
< IC >
IC801 8-759-826-34 IC NJL74H400A
(REMOTE CONTROL RECEIVER)
< TRANSISTOR >
Q801 8-729-900-53 TRANSISTOR DTC114EK
Q802 8-729-900-53 TRANSISTOR DTC114EK
Q803 8-729-900-53 TRANSISTOR DTC114EK
Q804 8-729-900-53 TRANSISTOR DTC114EK
Q805 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R812 1-216-821-11 METAL CHIP 1K 5% 1/10W
R813 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R814 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R815 1-216-821-11 METAL CHIP 1K 5% 1/10W
R816 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R817 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R818 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R819 1-216-833-11 METAL CHIP 10K 5% 1/10W
R820 1-216-821-11 METAL CHIP 1K 5% 1/10W
R821 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R822 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R823 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R824 1-216-833-11 METAL CHIP 10K 5% 1/10W
R825 1-216-837-11 METAL CHIP 22K 5% 1/10W
R831 1-216-817-11 METAL CHIP 470 5% 1/10W
R832 1-216-817-11 METAL CHIP 470 5% 1/10W
R833 1-216-817-11 METAL CHIP 470 5% 1/10W
R834 1-216-817-11 METAL CHIP 470 5% 1/10W
R835 1-216-817-11 METAL CHIP 470 5% 1/10W
R851 1-216-809-11 METAL CHIP 100 5% 1/10W
R852 1-216-809-11 METAL CHIP 100 5% 1/10W
R853 1-216-809-11 METAL CHIP 100 5% 1/10W
R854 1-216-809-11 METAL CHIP 100 5% 1/10W
R855 1-216-809-11 METAL CHIP 100 5% 1/10W
< ROTARY ENCODER >
RV801 1-476-730-11 ENCODER, ROTARY (VOLUME)
RV802 1-418-859-21 ENCODER, ROTARY (TREBLE)
RV803 1-418-859-21 ENCODER, ROTARY (BASS)
< SWITCH >
S801 1-762-875-21 SWITCH, TACTILE (I/1)
S802 1-762-875-21 SWITCH, TACTILE (DSG)
S803 1-762-875-21 SWITCH, TACTILE (TUNING +, M L)
S804 1-762-875-21 SWITCH, TACTILE (Z (CD))
S805 1-762-875-21 SWITCH, TACTILE (CD NX)
S806 1-762-875-21 SWITCH, TACTILE (x (CD))
S807 1-762-875-21 SWITCH, TACTILE (TUNING –, l m)
S808 1-762-875-21 SWITCH, TACTILE (REPEAT, FM MODE)
S809 1-762-875-21 SWITCH, TACTILE
(PLAY MODE/DIRECTION, TUNING MODE)
S810 1-762-875-21 SWITCH, TACTILE (FUNCTION)
S811 1-762-875-21 SWITCH, TACTILE (DISPLAY)
S812 1-762-875-21 SWITCH, TACTILE (CD SYNCHRO)
S813 1-762-875-21 SWITCH, TACTILE (TUNER BAND)
S814 1-762-875-21 SWITCH, TACTILE (z REC)
S815 1-762-875-21 SWITCH, TACTILE (X)
S816 1-762-875-21 SWITCH, TACTILE (x (TAPE))
S817 1-762-875-21 SWITCH, TACTILE (TAPE nN)
**************************************************************
A-4731-316-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C601 1-126-947-11 ELECT 47uF 20% 16V
C602 1-130-483-00 MYLAR 0.01uF 5% 50V
SUB POWER SWITCH TC
