Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
64
HCD-CPX1
C604 1-130-495-00 MYLAR 0.1uF 5% 50V
C605 1-126-964-11 ELECT 10uF 20% 50V
C606 1-126-960-11 ELECT 1uF 20% 50V
C607 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C608 1-126-961-11 ELECT 2.2uF 20% 50V
C610 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C611 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C612 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C613 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C614 1-130-483-00 MYLAR 0.01uF 5% 50V
C630 1-126-933-11 ELECT 100uF 20% 16V
C632 1-126-964-11 ELECT 10uF 20% 50V
C633 1-126-964-11 ELECT 10uF 20% 50V
C634 1-126-964-11 ELECT 10uF 20% 50V
C635 1-126-960-11 ELECT 1uF 20% 50V
C639 1-126-964-11 ELECT 10uF 20% 50V
C640 1-126-947-11 ELECT 47uF 20% 16V
C641 1-126-961-11 ELECT 2.2uF 20% 50V
C642 1-137-150-11 MYLAR 0.01uF 5% 100V
C643 1-130-485-00 MYLAR 0.015uF 5% 50V
C644 1-130-481-00 MYLAR 0.0068uF 5% 50V
C645 1-130-481-00 MYLAR 0.0068uF 5% 50V
C646 1-130-486-00 MYLAR 0.018uF 10% 50V
C647 1-126-964-11 ELECT 10uF 20% 50V
C651 1-126-947-11 ELECT 47uF 20% 16V
C652 1-130-483-00 MYLAR 0.01uF 5% 50V
C654 1-130-495-00 MYLAR 0.1uF 5% 50V
C655 1-126-964-11 ELECT 10uF 20% 50V
C656 1-126-960-11 ELECT 1uF 20% 50V
C657 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C658 1-126-961-11 ELECT 2.2uF 20% 50V
C660 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C661 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C662 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C663 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C664 1-130-483-00 MYLAR 0.01uF 5% 50V
C681 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN602 1-770-516-31 CONNECTOR, FFC 8P
CN603 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D681 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC601 6-701-655-01 IC HA12236F
IC602 8-759-508-69 IC BA3126N
< SHORT >
JR602 1-216-296-11 SHORT CHIP 0
JW630 1-216-864-11 SHORT CHIP 0
< COIL >
L601 1-410-780-11 INDUCTOR 27mH
L651 1-410-780-11 INDUCTOR 27mH
< TRANSISTOR >
Q639 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q640 8-729-029-66 TRANSISTOR DTC114ESA
Q641 8-729-801-93 TRANSISTOR 2SD1387
Q642 8-729-142-46 TRANSISTOR 2SC2001-LK
Q643 8-729-142-46 TRANSISTOR 2SC2001-LK
Q680 8-729-029-66 TRANSISTOR DTC114ESA
Q681 8-729-029-40 TRANSISTOR DTA124ESA
Q691 8-729-900-53 TRANSISTOR DTC114EK
Q692 8-729-900-53 TRANSISTOR DTC114EK
Q693 8-729-140-04 TRANSISTOR 2SB1116A-L
Q694 8-729-116-57 TRANSISTOR 2SB1068-K
< RESISTOR >
R601 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R603 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R605 1-216-841-11 METAL CHIP 47K 5% 1/10W
R606 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R607 1-216-833-11 METAL CHIP 10K 5% 1/10W
R609 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R610 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R611 1-216-837-11 METAL CHIP 22K 5% 1/10W
R630 1-216-857-11 METAL CHIP 1M 5% 1/10W
R631 1-216-837-11 METAL CHIP 22K 5% 1/10W
R632 1-216-821-11 METAL CHIP 1K 5% 1/10W
R633 1-216-833-11 METAL CHIP 10K 5% 1/10W
R635 1-216-809-11 METAL CHIP 100 5% 1/10W
R640 1-216-833-11 METAL CHIP 10K 5% 1/10W
R641 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R642 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0R643 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
0R644 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
R645 1-216-836-11 METAL CHIP 18K 5% 1/10W
R646 1-216-836-11 METAL CHIP 18K 5% 1/10W
R647 1-216-837-11 METAL CHIP 22K 5% 1/10W
R648 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R651 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R652 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R653 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R655 1-216-841-11 METAL CHIP 47K 5% 1/10W
R656 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R659 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R660 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R661 1-216-837-11 METAL CHIP 22K 5% 1/10W
R680 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R681 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R682 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R683 1-216-819-11 METAL CHIP 680 5% 1/10W
R684 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R685 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R686 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R687 1-216-841-11 METAL CHIP 47K 5% 1/10W
R688 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
TC
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
