Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
65
HCD-CPX1
R689 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R690 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R691 1-216-833-11 METAL CHIP 10K 5% 1/10W
R692 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R693 1-216-841-11 METAL CHIP 47K 5% 1/10W
R694 1-216-837-11 METAL CHIP 22K 5% 1/10W
R695 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV602 1-241-765-11 RES, ADJ, CARBON 22K
RV603 1-241-768-11 RES, ADJ, CARBON 220K
RV652 1-241-765-11 RES, ADJ, CARBON 22K
RV653 1-241-768-11 RES, ADJ, CARBON 220K
< TRANSFORMER >
T601 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
**************************************************************
MISCELLANEOUS
**************
52 1-796-456-31 DECK, MECHANICAL
54 1-824-192-11 WIRE (FLAT TYPE) (8 CORE)
55 1-773-110-11 WIRE (FLAT TYPE) (19 CORE)
105 1-776-183-11 WIRE (FLAT TYPE) (19 CORE)
155 1-769-916-11 WIRE (FLAT TYPE) (9 CORE)
253 1-824-930-11 WIRE (FLAT TYPE) (21 CORE)
0255 1-769-079-22 CORD, POWER (KR)
0255 1-777-071-83 CORD, POWER (SP)
0255 1-783-203-12 CORD, POWER (AUS)
0255 1-783-531-31 CORD, POWER (US, CND)
256 1-693-603-31 TUNER UNIT (SP, AUS)
256 1-693-605-11 TUNER UNIT (KR)
256 1-693-623-31 TUNER UNIT (US, CND)
257 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
0302 1-468-729-11 REGULATOR, SWITCHING (US, CND)
0302 1-468-730-11 REGULATOR, SWITCHING (SP, KR, AUS)
304 1-500-484-21 CLAMP, SLEEVE FERRITE
305 1-773-152-11 WIRE (FLAT TYPE) (21 CORE)
513 A-4735-082-A MAGNET ASSY
0557 8-820-020-11 OPTICAL PICK-UP KSS-213D/Z-RP
558 1-792-024-11 WIRE (FLAT TYPE) (16 CORE)
M101 X-2161-802-1 CHASSIS ASSY (DCP), T.T (SPINDLE)
M102 X-2625-769-1 GEAR ASSY (MB) (RP), MOTOR (SLED)
M201 A-4735-337-A MOTOR (LD) ASSY (LOADING)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
