Sony HCD-CQ1 - Panel (Top) Assy

10
HCD-CQ1
3-2. Panel (Top) Assy
2 Insert a screwdriver of 4mm diameter and release the
claws by raising the panel (top) assy gently.
7 FFC 33p (425)
8 panel (top) assy
6 cm
13 cm
6 cm
13 cm
3
4
5
1
6
(Location of the claws.)
If the main power cannot be turned on,
slide the CDM chassis using a screwdriver
in order to raise the panel (top) assy.
