Sony HCD-CQ1 - REMOCON Board, Panel (Front) Assy; CONTROL Board

14
HCD-CQ1
3-9. REMOCON Board, Panel (Front) Assy
3-10. CONTROL Board
1 two screws
(+BVTP 2.6
× 8
)
4 two screws
(+BVTP 2.6
× 8)
7 screw
(+BVTP 2.6
× 8)
2 clamp (L35)
6 panel (front) assy
8 panel (side-L)
3 connector (CN253)
5 REMOCON board
2 two screws
(+BTTP M2.6)
1 screw
(+BVTP 2.6
× 8)
4 panel (side-R )
3 CONTROL board
