Sony HCD-CQ1 - JACK Board, REG Board; Bearing Assy, Bushing (Guide A)

12
HCD-CQ1
3-5. JACK Board, REG Board
3-6. Bearing Assy, Bushing (Guide A)
2 FFC 11p (180)
3 JACK board
6 REG board
1 screw
(+BVTP 3
× 8)
4 screw
(+BVTP 3
× 8)
5 connector (CN961)
5 two screws
(+BVTP 3
× 8)
9 three screws
(+BVTP 3
× 8)
1 screw
(+BVTP 3
× 8)
qa two screws
(+BVTT 3
× 6)
qs two screws
(+BVTP 2.6
× 8)
q; screw
(+BVTP 3
× 8)
qf chassis
(CDM)
2 chassis
(guide L)
6 chassis
(guide R)
8 bushing
(guide A)
7 two claws
4 bearing assy
3 three screws
(+BTTP M2.6)
qd guide (front panel)
