Sony HCD-CQ1 - Kss-213 D;Q-Rp; Slider (R), Slider (L)

16
HCD-CQ1
3-14. Slider (R), Slider (L)
2 guide (R)
8 guide (L)
6 slider (R)
qs slider (L)
1 two screws
(+BVTP 2.6
× 8
)
7 two screws
(+BVTP 2.6
× 8)
3 screw
(+PTPWH M2.6)
9 screw
(+PTPWH M2.6)
qa two brackets
5 two brackets
qf MD base
qd slider (S)
4 two screws
(DIA.12)
q; two screws
(DIA.12)
CDM76-K6BD44S
3-13. KSS-213D/Q-RP
2 gear (A)
1 claw
5 sled shaft
6 KSS-213D/ Q-RP
4
3
