Sony HCD-CQ1 - Chassis Section-1

38
HCD-CQ1
7-2. Chassis Section-1
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51 X-4955-635-1 BEARING ASSY
52 4-218-253-21 SCREW (M2.6), +BTTP
53 4-244-753-01 BUSHING (GUIDE A)
54 4-951-620-01 SCREW (2.6X8), +BVTP
55 3-559-407-01 CUSHION, STOPPER
56 3-378-109-12 CUSHION, SARANET
#4 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
#5 7-685-871-01 SCREW +BVTT 3X6 (S)
Ver 1.1 2003.06
51
54
55
56
52
not supplied
not supplied
not
supplied
not supplied
CDM76-K6BD44S
not supplied
chassis assy
53
#4
#4
#4
#5
#5
#4
#4
54
