Sony HCD-CQ1 - Page 45

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
45
HCD-CQ1
R120 1-216-835-11 METAL CHIP 15K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-845-11 METAL CHIP 100K 5% 1/16W
R131 1-216-813-11 METAL CHIP 220 5% 1/16W
R143 1-216-836-11 METAL CHIP 18K 5% 1/16W
R144 1-216-836-11 METAL CHIP 18K 5% 1/16W
R147 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R148 1-216-791-11 METAL CHIP 3.3 5% 1/16W
R150 1-216-833-11 METAL CHIP 10K 5% 1/16W
R151 1-216-846-11 METAL CHIP 120K 5% 1/16W
R158 1-216-837-11 METAL CHIP 22K 5% 1/16W
R159 1-216-837-11 METAL CHIP 22K 5% 1/16W
R162 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R171 1-216-837-11 METAL CHIP 22K 5% 1/16W
R172 1-216-837-11 METAL CHIP 22K 5% 1/16W
R173 1-216-837-11 METAL CHIP 22K 5% 1/16W
R181 1-216-837-11 METAL CHIP 22K 5% 1/16W
R182 1-216-837-11 METAL CHIP 22K 5% 1/16W
R183 1-216-837-11 METAL CHIP 22K 5% 1/16W
R191 1-216-839-11 METAL CHIP 33K 5% 1/16W
R192 1-216-839-11 METAL CHIP 33K 5% 1/16W
R193 1-216-847-11 METAL CHIP 150K 5% 1/16W
R194 1-216-843-11 METAL CHIP 68K 5% 1/16W
R195 1-216-851-11 METAL CHIP 330K 5% 1/16W
R196 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R197 1-216-821-11 METAL CHIP 1K 5% 1/16W
<COMPOSITION CIRCUIT BLOCK>
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
A-4731-456-A CONTROL BOARD, COMPLETE (US,CND)
A-4731-469-A CONTROL BOARD, COMPLETE (AEP,UK)
A-4731-474-A CONTROL BOARD, COMPLETE (SP)
A-4731-479-A CONTROL BOARD, COMPLETE (HK)
A-4731-484-A CONTROL BOARD, COMPLETE (AUS)
A-4731-489-A CONTROL BOARD, COMPLETE (TW)
A-4731-494-A CONTROL BOARD, COMPLETE (KR)
A-4731-499-A CONTROL BOARD, COMPLETE (MX)
*************************
< CAPACITOR >
C101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C112 1-124-589-11 ELECT 47uF 20% 16V
C113 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C114 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C151 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C152 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C153 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C154 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C165 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C166 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C190 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-124-589-11 ELECT 47uF 20% 16V
C202 1-136-165-00 FILM 0.1uF 5.00% 50V
C203 1-136-165-00 FILM 0.1uF 5.00% 50V
C204 1-124-261-00 ELECT 10uF 20% 50V
C232 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C241 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C251 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C252 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C253 1-124-261-00 ELECT 10uF 20% 50V
C261 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C262 1-128-834-11 ELECT 470uF 20% 10V
C264 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C265 1-126-176-11 ELECT 220uF 20% 10V
C266 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C267 1-162-953-11 ERAMIC CHIP 100PF 5% 50V
C268 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C269 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C270 1-128-832-11 ELECT 220uF 20% 10V
C271 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C275 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-784-753-11 CONNECTOR, FFC 31P
CN102 1-784-389-21 CONNECTOR, FFC/FPC 33P
CN104 1-568-830-11 CONNECTOR, FFC 11P
CN251 1-568-838-11 CONNECTOR, FFC 21P
CN252 1-785-317-11 PIN, CONNECTOR (STRAIGHT) 5P
CN253 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D102 8-719-988-61 DIODE 1SS355TE-17
D103 8-719-988-61 DIODE 1SS355TE-17
D104 8-719-988-61 DIODE 1SS355TE-17
D106 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
D203 8-719-988-61 DIODE 1SS355TE-17
D204 8-719-988-61 DIODE 1SS355TE-17
D205 8-719-988-61 DIODE 1SS355TE-17
D206 8-719-988-61 DIODE 1SS355TE-17
D207 8-719-988-61 DIODE 1SS355TE-17
D251 8-719-056-82 DIODE UDZ-TE-17-6.2B
D252 8-719-051-07 DIODE EC10DA40
D253 8-719-051-07 DIODE EC10DA40
D254 8-719-051-07 DIODE EC10DA40
<TERMINAL BOARD>
EP101 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD/RESISTOR >
FB115 1-500-445-21 FERRITE 0uH
FB131 1-216-864-11 METAL CHIP 0 5% 1/16W
CONTROLBD
