HCD-CX4iP/CX5iP
11
2-7. BASE UNIT (BU-F4BD94D-V)
2-6. BELT (MOT)
– CD mechanism deck block bottom view –
1
belt (MOT)
4
– CD mechanism deck block bottom view –
3
three floating screws
(PTPWH M2.6)
3
floating screw
(PTPWH M2.6)
1
tension coil spring (G-1)
2
tension coil spring (G-2)
5
vibration proof rubber
5
vibration proof rubber
5
vibration proof rubber
5
vibration proof rubber
6
base unit
(BU-F4BD94D-V)
