Sony HCD-CX5iP - CD Mechanism Deck Section (CDM80 BTK-F4 BD94 D-V)

44
HCD-CX4iP/CX5iP
5-5. CD MECHANISM DECK SECTION (CDM80BTK-F4BD94D-V)
201 A-1810-163-A CDM80BTK ASSY (including DRIVER board)
202 4-245-653-11 BELT (MOT)
203 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING
204 4-992-054-11 RUBBER, VIBRATION PROOF
205 2-059-837-01 SPRING (G-1), TENSION COIL
206 2-059-838-01 SPRING (G-2), TENSION COIL
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
204
204
203
204
203
203
204
201 (including DRIVER board)
205
206
202
not supplied
not supplied
(DRIVER board)
base unit section
(BU-F4BD94D-V)
