Sony HCD-CX5iP - Base Unit Section (BU-F4 BD94 D-V)

45
HCD-CX4iP/CX5iP
5-6. BASE UNIT SECTION (BU-F4BD94D-V)
0 251 8-820-252-03 OPTICAL PICK-UP (KSM-215CFP/C2NP)
(including sled motor and spindle motor)
252 1-834-268-21 WIRE (FLAT TYPE) (16 CORE)
253 A-1805-057-A BD94D-V BOARD, COMPLETE
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
251
(including sled motor,
spindle motor)
252
sled motor
spindle motor
253
S201
