— 115 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D301 8-719-987-63 DIODE 1N4148M
D302 8-719-987-63 DIODE 1N4148M
D303 8-719-987-63 DIODE 1N4148M
D321 8-719-815-85 DIODE 1S1585
(D90AV/GR10AV/RX100AV:US,CND)
D321 8-719-987-63 DIODE 1N4148M (RX100AV:AEP,UK,G,EE,CIS)
D331 8-719-987-63 DIODE 1N4148M
D332 8-719-987-63 DIODE 1N4148M
D401 8-719-987-63 DIODE 1N4148M
D402 8-719-987-63 DIODE 1N4148M
D403 8-719-815-85 DIODE 1S1585
D404 8-719-815-85 DIODE 1S1585
D405 8-719-815-85 DIODE 1S1585
D406 8-719-815-85 DIODE 1S1585
< EARTH >
* EP101 1-537-738-21 TERMINAL, EARTH
* EP201 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F101 1-532-464-31 FUSE, TIME-LAG (2.5A/250V)(GR10AV)
! F101 1-532-465-31 FUSE, TIME-LAG (3.15A/250V)
(RX100AV:AEP,UK,G,EE,CIS)
! F101 1-533-690-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(3.15A/125V)(D90AV/RX100AV:US,CND)
! F102 1-532-464-31 FUSE, TIME-LAG (2.5A/250V)(GR10AV)
! F102 1-532-465-31 FUSE, TIME-LAG (3.15A/250V)
(RX100AV:AEP,UK,G,EE,CIS)
! F102 1-533-690-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(3.15A/125V)(D90AV/RX100AV:US,CND)
! F103 1-532-506-31 FUSE, TIME-LAG (6.3A/250V)
(GR10AV/RX100AV:AEP,UK,G,EE,CIS)
! F103 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(6.3A/125V)(D90AV/RX100AV:US,CND)
! F104 1-532-506-31 FUSE, TIME-LAG (6.3A/250V)
(GR10AV/RX100AV:AEP,UK,G,EE,CIS)
! F104 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(6.3A/125V)(D90AV/RX100AV:US,CND)
< FUSE HOLDER >
FH101 1-533-233-21 HOLDER, FUSE
FH102 1-533-233-21 HOLDER, FUSE
FH103 1-533-233-21 HOLDER, FUSE
FH104 1-533-233-21 HOLDER, FUSE
FH105 1-533-233-21 HOLDER, FUSE
FH106 1-533-233-21 HOLDER, FUSE
FH107 1-533-233-21 HOLDER, FUSE
FH108 1-533-233-21 HOLDER, FUSE
< IC >
IC201 8-749-921-68 IC STK-4231MK2 (D90AV/RX100AV:US,CND)
IC201 8-749-922-65 IC STK-4221MK2 (GR10AV)
IC201 8-749-900-34 IC STK-4182MK2 (RX100AV:AEP,UK,G,EE,CIS)
IC301 8-759-111-68 IC UPC1237HA
< COIL >
L401 1-420-872-00 COIL, AIR-CORE (RX100AV:AEP,UK,G,EE,CIS)
L402 1-420-872-00 COIL, AIR-CORE (RX100AV:AEP,UK,G,EE,CIS)
L403 1-420-872-00 COIL, AIR-CORE (RX100AV:AEP,UK,G,EE,CIS)
L404 1-420-872-00 COIL, AIR-CORE (RX100AV:AEP,UK,G,EE,CIS)
< TRANSISTOR >
Q111 8-729-900-80 TRANSISTOR DTC114ES
(RX100AV:AEP,UK,G,EE,CIS)
Q112 8-729-900-80 TRANSISTOR DTC114ES
(RX100AV:AEP,UK,G,EE,CIS)
Q113 8-729-040-20 TRANSISTOR RT1P137L-TP
(RX100AV:AEP,UK,G,EE,CIS)
Q201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q301 8-729-900-89 TRANSISTOR DTC144ES
Q323 8-729-900-63 TRANSISTOR DTA124ES
Q331 8-729-900-89 TRANSISTOR DTC144ES
Q401 8-729-900-80 TRANSISTOR DTC114ES
Q402 8-729-904-39 TRANSISTOR DTC114TS
Q403 8-729-040-20 TRANSISTOR RT1P137L-TP
Q404 8-729-040-20 TRANSISTOR RT1P137L-TP
Q405 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
! R101 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
! R103 1-216-449-11 METAL OXIDE 56 5% 2W F
(RX100AV:AEP,UK,G,EE,CIS)
R111 1-249-429-11 CARBON 10K 5% 1/4W
(RX100AV:AEP,UK,G,EE,CIS)
R201 1-249-417-11 CARBON 1K 5% 1/4W F
R202 1-249-437-11 CARBON 47K 5% 1/4W
R203 1-249-413-11 CARBON 470 5% 1/4W F
(D90AV/GR10AV/RX100AV:US,CND)
R203 1-249-415-11 CARBON 680 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R204 1-249-437-11 CARBON 47K 5% 1/4W
R206 1-260-107-11 CARBON 4.7K 5% 1/2W
(D90AV/GR10AV/RX100AV:US,CND)
R206 1-260-105-11 CARBON 3.3K 5% 1/2W
(RX100AV:AEP,UK,G,EE,CIS)
R208 1-260-107-11 CARBON 4.7K 5% 1/2W
(D90AV/GR10AV/RX100AV:US,CND)
R208 1-260-105-11 CARBON 3.3K 5% 1/2W
(RX100AV:AEP,UK,G,EE,CIS)
! R209 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R210 1-217-156-00 WIREWOUND 0.22 10% 5W
(D90AV/GR10AV/RX100AV:US,CND)
! R210 1-217-151-00 METAL PLATE 0.22 10% 2W
(RX100AV:AEP,UK,G,EE,CIS)
R211 1-249-417-11 CARBON 1K 5% 1/4W F
R212 1-249-431-11 CARBON 15K 5% 1/4W
R213 1-249-441-11 CARBON 100K 5% 1/4W
R215 1-260-102-11 CARBON 1.8K 5% 1/2W
(D90AV/RX100AV:US,CND)
R215 1-260-103-11 CARBON 2.2K 5% 1/2W
(GR10AV)
R215 1-260-099-11 CARBON 1K 5% 1/2W
(RX100AV:AEP,UK,G,EE,CIS)
R216 1-260-102-11 CARBON 1.8K 5% 1/2W
(D90AV/RX100AV:US,CND)
R216 1-260-103-11 CARBON 2.2K 5% 1/2W
(GR10AV)
POWER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
