— 116 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R216 1-260-099-11 CARBON 1K 5% 1/2W
(RX100AV:AEP,UK,G,EE,CIS)
R218 1-260-076-11 CARBON 10 5% 1/2W
R227 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R250 1-217-637-00 FUSIBLE 1 5% 1/4W F
R251 1-249-417-11 CARBON 1K 5% 1/4W F
R252 1-249-437-11 CARBON 47K 5% 1/4W
R253 1-249-413-11 CARBON 470 5% 1/4W F
(D90AV/GR10AV/RX100AV:US,CND)
R253 1-249-415-11 CARBON 680 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R254 1-249-437-11 CARBON 47K 5% 1/4W
R256 1-260-107-11 CARBON 4.7K 5% 1/2W
(D90AV/GR10AV/RX100AV:US,CND)
R256 1-260-105-11 CARBON 3.3K 5% 1/2W
(RX100AV:AEP,UK,G,EE,CIS)
R258 1-260-107-11 CARBON 4.7K 5% 1/2W
(D90AV/GR10AV/RX100AV:US,CND)
R258 1-260-105-11 CARBON 3.3K 5% 1/2W
(RX100AV:AEP,UK,G,EE,CIS)
! R259 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R260 1-217-156-00 WIREWOUND 0.22 10% 5W
(D90AV/GR10AV/RX100AV:US,CND)
! R260 1-217-151-00 METAL PLATE 0.22 10% 2W
(RX100AV:AEP,UK,G,EE,CIS)
R261 1-249-417-11 CARBON 1K 5% 1/4W F
R262 1-249-431-11 CARBON 15K 5% 1/4W
R263 1-249-441-11 CARBON 100K 5% 1/4W
R268 1-260-076-11 CARBON 10 5% 1/2W
R272 1-260-093-11 CARBON 330 5% 1/2W
R273 1-260-093-11 CARBON 330 5% 1/2W
R274 1-260-093-11 CARBON 330 5% 1/2W
R275 1-260-093-11 CARBON 330 5% 1/2W
R301 1-249-441-11 CARBON 100K 5% 1/4W
R302 1-247-854-11 CARBON 9.1K 5% 1/4W
(D90AV/GR10AV/RX100AV:US,CND)
R302 1-249-425-11 CARBON 4.7K 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R303 1-247-854-11 CARBON 9.1K 5% 1/4W
(D90AV/GR10AV/RX100AV:US,CND)
R303 1-249-425-11 CARBON 4.7K 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R304 1-249-429-11 CARBON 10K 5% 1/4W
R305 1-249-421-11 CARBON 2.2K 5% 1/4W F
R306 1-249-441-11 CARBON 100K 5% 1/4W
R307 1-247-863-91 CARBON 22K 5% 1/4W
R308 1-247-863-91 CARBON 22K 5% 1/4W
R309 1-247-791-91 CARBON 22 5% 1/4W
R310 1-249-437-11 CARBON 47K 5% 1/4W
(D90AV/GR10AV/RX100AV:US,CND)
R310 1-249-435-11 CARBON 33K 5% 1/4W
(RX100AV:AEP,UK,G,EE,CIS)
R311 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-429-11 CARBON 10K 5% 1/4W
R314 1-249-439-11 CARBON 68K 5% 1/4W
R315 1-249-439-11 CARBON 68K 5% 1/4W
R316 1-249-437-11 CARBON 47K 5% 1/4W
R317 1-249-437-11 CARBON 47K 5% 1/4W
R331 1-247-889-00 CARBON 270K 5% 1/4W
(D90AV/RX100AV:US,CND)
R331 1-247-890-11 CARBON 300K 5% 1/4W
(GR10AV)
R331 1-247-883-00 CARBON 150K 5% 1/4W
(RX100AV:AEP,UK,G,EE,CIS)
R332 1-249-429-11 CARBON 10K 5% 1/4W
R333 1-249-431-11 CARBON 15K 5% 1/4W
(D90AV/GR10AV/RX100AV:US,CND)
R333 1-249-429-11 CARBON 10K 5% 1/4W
(RX100AV:AEP,UK,G,EE,CIS)
R334 1-249-417-11 CARBON 1K 5% 1/4W F
! R405 1-215-886-11 METAL OXIDE 100 5% 2W F
! R407 1-215-886-11 METAL OXIDE 100 5% 2W F
R408 1-249-437-11 CARBON 47K 5% 1/4W
R409 1-249-440-11 CARBON 82K 5% 1/4W
R410 1-249-437-11 CARBON 47K 5% 1/4W
R411 1-249-437-11 CARBON 47K 5% 1/4W
R412 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R413 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R414 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R415 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R416 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R417 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R418 1-249-393-11 CARBON 10 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R419 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R420 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R421 1-249-393-11 CARBON 10 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R422 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
R423 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX100AV:AEP,UK,G,EE,CIS)
< RELAY >
! RY101 1-755-195-11 RELAY (RX100AV:AEP,UK,G,EE,CIS)
RY401 1-755-142-11 RELAY
RY402 1-755-141-11 RELAY (D90AV/GR10AV/RX100AV:US,CND)
RY402 1-755-142-11 RELAY (RX100AV:AEP,UK,G,EE,CIS)
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-510-11 TERMINAL BOARD (SPEAKER) (6P)
(SURROUND SPEAKER)
**************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 PH OTO INTERRUPTER RPI-1391
IC703 8-749-924-30 PH OTO REFLECTOR GP2S28
POWER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
SENSOR
To Next Page
