— 122 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-4392-652-A TC SW BOARD, COMPLETE
**********************
< CONNECTOR >
CN607 1-506-486-11 PIN, CONNECTOR 7P
< DIODE >
D634 8-719-063-92 DIODE SLR325MC-M-T31-NP (·)(DECK B)
D635 8-719-063-92 DIODE SLR325MC-M-T31-NP (ª)(DECK B)
D636 8-719-063-91 DIODE SLR325DC-P-T32 (P PAUSE)
D637 8-719-063-93 DIODE SLR325VC-N-T32 (r REC)
D638 8-719-063-92 DIODE SLR325MC-M-T31-NP (·)(DECK A)
D639 8-719-063-92 DIODE SLR325MC-M-T31-NP (ª)(DECK A)
< TRANSISTOR >
Q617 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q618 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q619 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R726 1-249-401-11 CARBON 47 5% 1/4W F
R727 1-249-403-11 CARBON 68 5% 1/4W F
R728 1-247-807-31 CARBON 100 5% 1/4W
R729 1-249-407-11 CARBON 150 5% 1/4W F
R730 1-249-407-11 CARBON 150 5% 1/4W F
R731 1-247-815-91 CARBON 220 5% 1/4W
R732 1-249-411-11 CARBON 330 5% 1/4W
R733 1-249-413-11 CARBON 470 5% 1/4W F
R734 1-249-415-11 CARBON 680 5% 1/4W F
R735 1-249-417-11 CARBON 1K 5% 1/4W F
R736 1-249-419-11 CARBON 1.5K 5% 1/4W F
R737 1-249-421-11 CARBON 2.2K 5% 1/4W F
R738 1-247-843-11 CARBON 3.3K 5% 1/4W
R739 1-249-427-11 CARBON 6.8K 5% 1/4W F
R740 1-247-807-31 CARBON 100 5% 1/4W
R741 1-247-807-31 CARBON 100 5% 1/4W
R742 1-247-807-31 CARBON 100 5% 1/4W
R743 1-247-815-91 CARBON 220 5% 1/4W
R744 1-247-807-31 CARBON 100 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S655 1-762-196-21 SWITCH, TACT (·)(DECK B)
S656 1-762-196-21 SWITCH, TACT (ª)(DECK B)
S657 1-762-196-21 SWITCH, TACT ())(DECK B)
S658 1-762-196-21 SWITCH, TACT (0)(DECK B)
S659 1-762-196-21 SWITCH, TACT (p)(DECK B)
S660 1-762-196-21 SWITCH, TACT (P PAUSE)
S661 1-762-196-21 SWITCH, TACT (r REC)
S662 1-762-196-21 SWITCH, TACT (CD SYNCHRO)
S663 1-762-196-21 SWITCH, TACT (HIGH SPEED DUBBING)
S664 1-762-196-21 SWITCH, TACT ())(DECK A)
S665 1-762-196-21 SWITCH, TACT (0)(DECK A)
S666 1-762-196-21 SWITCH, TACT (p)(DECK A)
S667 1-762-196-21 SWITCH, TACT (·)(DECK A)
S668 1-762-196-21 SWITCH, TACT (ª)(DECK A)
**************************************************************
* 1-663-994-11 TRANS BOARD
***********
< CONNECTOR >
* CN501 1-564-527-11 PLUG, CONNECTOR 12P
CN502 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
! F501 1-532-505-31 FUSE, TIME-LAG (4A/250V)
(GR10AV:E,EA,SP,JE,HK,IA)
! F501 1-533-301-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(6.3A/125V)(D90AV/RX100AV: US,CND)
< FUSE HOLDER >
FH501 1-533-233-21 HOLDER, FUSE
(D90AV/GR10AV:E,EA,SP,JE,HK,IA/RX100AV: US,CND)
FH502 1-533-233-21 HOLDER, FUSE
(D90AV/GR10AV:E,EA,SP,JE,HK,IA/RX100AV: US,CND)
< RESISTOR >
! R501 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R502 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R503 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
! R506 1-202-725-00 SOLID 3.3M 10% 1/2W
(D90AV/RX100AV: US,CND)
< SWITCH >
! S501 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR)(GR10AV: E,EA,SP,JE,HK,IA)
< TRANSFORMER >
! T501 1-431-136-11 TRANSFORMER, POWER (AEP,UK,G,EE,CIS)
! T501 1-431-137-11 TRANSFORMER, POWER (US,CND)
! T501 1-431-138-11 TRANSFORMER, POWER
(E,EA,SP,JE,HK,MY,AUS,IA)
! T501 1-431-138-21 TRANSFORMER, POWER (TH)
*****************************************************************
MISCELLANEOUS
*************
2 1-751-086-11 WIRE (FLAT CABLE)(13 CORE)
(US,CND,E2,TH,AUS)
2 1-773-012-11 WIRE (FLAT CABLE) (15 CORE)
(Except US,CND,E2,TH,AUS)
3 1-233-544-11 ENCAPSULATED COMPONENT (US,CND)
3 1-233-545-11 ENCAPSULATED COMPONENT (E2,AUS,TH)
3 1-233-546-11 ENCAPSULATED COMPONENT
(E3,EA,HK,SP,JE,MY,IA)
5 1-773-158-11 WIRE (FLAT TYPE) (21 CORE)
6 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
7 1-769-948-11 WIRE (FLAT TYPE) (11 CORE)
8 1-777-870-11 WIRE (FLAT TYPE) (19 CORE)
! 57 1-569-007-11 ADAPTOR, CONVERSION 2P (E3,IA)
! 57 1-569-008-11 ADAPTOR, CONVERSION 2P (EA,SP,JE)
! 57 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
! 59 1-558-943-41 CORD, POWER (E,IA)
! 59 1-575-042-21 CORD, POWER (US,CND)
! 59 1-575-651-21 CORD, POWER (AEP,G,EE,CIS,EA,HK,SP,JE,MY)
TRANS
TC SW
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
