— 123 —
! 59 1-696-845-11 CORD, POWER (AUS)
! 59 1-751-326-21 CORD, POWER (TH)
! 59 1-751-529-11 CORD, POWER (UK)
104 1-769-909-11 WIRE (FLAT TYPE) (9 CORE)
105 1-777-869-11 WIRE (FLAT TYPE) (10 CORE) (Except US,CND)
105 1-777-871-11 WIRE (FLAT TYPE) (8 CORE) (US,CND)
106 1-777-936-11 WIRE (FLAT TYPE) (5 CORE) (Except US,CND)
407 1-452-538-11 MAGNET
408 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 451 8-820-020-01 OPTICAL PICK-UP BLOCK KSS-213D/Q-NP
452 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
FL601 1-517-618-11 INDICATOR, TUBE FLUORESCENT
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE)
M1 X-3371-223-1 MOTOR ASSY (CAPSTAN)
M2 A-2004-410-A MOTOR ASSY (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
M901 1-698-792-11 FAN, DC
S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET)
! T501 1-431-136-11 TRANSFORMER, POWER (AEP,UK,G,EE,CIS)
! T501 1-431-137-11 TRANSFORMER, POWER (US,CND)
! T501 1-431-138-11 TRANSFORMER, POWER
(E,EA,SP,JE,HK,MY,AUS,IA)
! T501 1-431-138-21 TRANSFORMER, POWER (TH)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-871-01 SCREW +BVTT 3X6 (S)
#5 7-685-872-09 SCREW +BVTT 3X8 (S)
#6 7-621-775-10 SCREW +B2.6X4
#7 7-621-255-15 SCREW +P2X3
#8 7-623-921-01 RING, RETAINING, CAPSTAN
#9 7-621-775-00 SCREW +B2.6X3
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#12 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#13 7-685-862-09 SCREW +BVTT 2.6X6 (S)
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
