53 CLTV I Control voltage input for master VCO.
54 FILO O Filter output for master PLL.
55 FILI I Filter input for master PLL.
56 PCO O Chage-pump output for master PLL.
57 AVDD3 I Analog powr supply.
58 VSS — Ground.
59 VDD I Power supply.
60 DOUT O Not used.
61 LRCK O Not used.
62 PCMD O Not used.
63 BCK O Not used.
64 EMPH O Not used.
65 XVDD I Master clock power supply.
66 XTAI I X’tal oscillator circuit input.
67 XTAO O X’tal oscillator circuit output.
68 XVSS — Master clock ground.
69 AVDD1 I Analog power supply.
70 AOUT1 O Lch : Analog output.
71 AIN1 I Lch : OPAMP input.
72 LOUT1 O Lch : LINE output
73 AVSS1 — Analog ground.
74 AVSS2 — Analog ground.
75 LOUT2 O Rch : LINE output.
76 AIN2 I Rch : OPAMP input.
77 AOUT2 O Rch : Analog output.
78 AVDD2 I Analog power supply.
79 RMUT O Not used.
80 LMUT O Not used.
FunctionPin NamePin No. I/O
