66
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP800AV
BD DRIVER
CD PANEL
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/16W
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-835-11 METAL CHIP 15K 5% 1/16W
R104 1-216-839-11 METAL CHIP 33K 5% 1/16W
R105 1-216-821-11 METAL CHIP 1K 5% 1/16W
R106 1-216-821-11 METAL CHIP 1K 5% 1/16W
R107 1-216-833-11 METAL CHIP 10K 5% 1/16W
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R109 1-216-857-11 METAL CHIP 1M 5% 1/16W
R111 1-216-846-11 METAL CHIP 120K 5% 1/16W
R114 1-218-745-11 RES-CHIP 160K 5% 1/16W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/16W
R118 1-216-809-11 METAL CHIP 100 5% 1/16W
R119 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R120 1-216-835-11 METAL CHIP 15K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-845-11 METAL CHIP 100K 5% 1/16W
R131 1-216-813-11 METAL CHIP 220 5% 1/16W
R143 1-216-839-11 METAL CHIP 33K 5% 1/16W
R144 1-216-839-11 METAL CHIP 33K 5% 1/16W
R147 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R148 1-216-797-11 METAL CHIP 10 5% 1/16W
R149 1-216-797-11 METAL CHIP 10 5% 1/16W
R158 1-216-838-11 METAL CHIP 27K 5% 1/16W
R159 1-216-838-11 METAL CHIP 27K 5% 1/16W
R162 1-216-845-11 METAL CHIP 100K 5% 1/16W
R171 1-216-837-11 METAL CHIP 22K 5% 1/16W
R172 1-216-837-11 METAL CHIP 22K 5% 1/16W
R173 1-216-837-11 METAL CHIP 22K 5% 1/16W
R181 1-216-837-11 METAL CHIP 22K 5% 1/16W
R182 1-216-837-11 METAL CHIP 22K 5% 1/16W
R183 1-216-837-11 METAL CHIP 22K 5% 1/16W
R190 1-216-813-11 METAL CHIP 220 5% 1/16W
R191 1-216-839-11 METAL CHIP 33K 5% 1/16W
R192 1-216-839-11 METAL CHIP 33K 5% 1/16W
R193 1-216-846-11 METAL CHIP 120K 5% 1/16W
R194 1-216-845-11 METAL CHIP 100K 5% 1/16W
R195 1-216-853-11 METAL CHIP 470K 5% 1/16W
R196 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R198 1-216-864-11 METAL CHIP 0 5% 1/16W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR>
RV101 1-238-602-11 RES, ADJ, CARBON 47K (RF BALANCE)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
******************************************************
CD PANEL BOARD (included in PANEL BOARD)
*************
< DIODE >
D1114 8-719-057-97 DIODE SEL5923A-TP15 (DISC 1)
D1115 8-719-057-97 DIODE SEL5923A-TP15 (DISC 2)
D1116 8-719-057-97 DIODE SEL5923A-TP15 (DISC 3)
D1117 8-719-071-44 DIODE SELS5223C-TP15 ( `/1)
< TRANSISTOR >
Q1114 8-729-900-80 TRANSISTOR DTC114ES
Q1115 8-729-900-80 TRANSISTOR DTC114ES
Q1116 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R1138 1-249-407-11 CARBON 150 5% 1/4W F
R1139 1-249-407-11 CARBON 150 5% 1/4W F
R1140 1-249-407-11 CARBON 150 5% 1/4W F
R1141 1-249-417-11 CARBON 1K 5% 1/4W F
R1150 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1151 1-249-422-11 CARBON 2.7K 5% 1/4W F
R1152 1-249-424-11 CARBON 3.9K 5% 1/4W F
R1153 1-249-426-11 CARBON 5.6K 5% 1/4W
R1154 1-249-428-11 CARBON 8.2K 5% 1/4W F
< SWITCH >
S1110 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE Z)
S1111 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP EX-CHANGE)
S1112 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S1113 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S1114 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S1115 1-762-875-21 SWITCH, KEYBOARD (`/1)
******************************************************
1-675-911-14 CD SENSOR BOARD
***************
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< IC >
IC711 8-749-016-76 IC RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN SW)
******************************************************
1-675-912-14 DRIVER BOARD
************
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-983-68 DIODE MTZJ-T-72-3.9A
CD SENSOR
Ver 1.2 2002.03
