68
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP800AV
DSP
C709 1-126-964-11 ELECT 10uF 20% 50V
C710 1-126-964-11 ELECT 10uF 20% 50V
C711 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C712 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C713 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C714 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C715 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C716 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C717 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C719 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C720 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C721 1-126-934-11 ELECT 220uF 20% 10V
C722 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C723 1-126-964-11 ELECT 10uF 20% 50V
C724 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C725 1-126-964-11 ELECT 10uF 20% 50V
C726 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C727 1-126-964-11 ELECT 10uF 20% 50V
C728 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C729 1-126-964-11 ELECT 10uF 20% 50V
C730 1-126-964-11 ELECT 10uF 20% 50V
C731 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C732 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C733 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C734 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C735 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C736 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C738 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C739 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C740 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C741 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C742 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
< CONNECTOR >
* CN601 1-568-941-11 PIN, CONNECTOR 3P
CN602 1-779-289-11 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN603 1-779-291-11 CONNECTOR,FFC(LIF(NON-ZIF))23P
< DIODE >
D601 8-719-158-02 DIODE RD3.9SB2
D604 8-719-988-61 DIODE 1SS355TE-17
D605 8-719-988-61 DIODE 1SS355TE-17
D606 8-719-988-61 DIODE 1SS355TE-17
D607 8-719-058-24 DIODE RB501V-40TE-17 (AR,MX)
D608 8-719-058-24 DIODE RB501V-40TE-17 (AR,MX)
D609 8-719-058-24 DIODE RB501V-40TE-17 (AR,MX)
D610 8-719-058-24 DIODE RB501V-40TE-17 (AR,MX)
< EARTH TERMINAL >
* EP601 1-537-738-21 TERMINAL, EARTH
* EP602 1-537-738-21 TERMINAL, EARTH
* EP603 1-537-738-21 TERMINAL, EARTH
* EP604 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB601 1-216-864-11 METAL CHIP 0 5% 1/16W
FB602 1-216-864-11 METAL CHIP 0 5% 1/16W
FB603 1-500-445-21 FERRITE 0UH
FB604 1-216-864-11 METAL CHIP 0 5% 1/16W
FB605 1-216-864-11 METAL CHIP 0 5% 1/16W
FB606 1-216-805-11 METAL CHIP 47 5% 1/16W
FB607 1-500-445-21 FERRITE 0UH
FB608 1-500-445-21 FERRITE 0UH
FB609 1-500-445-21 FERRITE 0UH
< IC >
IC601 8-759-698-76 IC CXD9617R
IC602 8-759-827-81 IC IS61LV6416-15T(T&R)
IC603 8-759-238-47 IC TC74HCT7007AF(EL)
IC604 8-759-825-15 IC LC89056W-E
IC605 8-759-657-47 IC AK4527
IC606 8-759-825-13 IC PCM1748E/2K
IC607 8-749-018-85 IC M61512FP
IC608 8-759-549-25 IC SN74LVU04APWR
IC609 8-749-923-04 IC TOTX178A (DIGITAL OUT (OPTICAL))
IC610 8-759-835-63 IC NJM2391DL1-26-TE1
< JACK >
J601 1-770-890-11 JACK, PIN 6P (GAME/MD(VIDEO))
J602 1-774-785-11 JACK, PIN 1P (SUB WOOFER OUT)
< JUMPER RESISTOR >
JR601 1-216-864-11 METAL CHIP 0 5% 1/16W
JR603 1-216-864-11 METAL CHIP 0 5% 1/16W
JR620 1-216-864-11 METAL CHIP 0 5% 1/16W
JR621 1-216-864-11 METAL CHIP 0 5% 1/16W
JR622 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q601 8-729-801-93 TRANSISTOR 2SD1387-3
Q602 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q603 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q604 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q605 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q606 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q607 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q608 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q609 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q610 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q611 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q612 8-729-113-69 TRANSISTOR FN1F4M-M32
Q613 8-729-113-13 TRANSISTOR FA1A4M-L33
< RESISTOR >
R601 1-216-809-11 METAL CHIP 100 5% 1/16W
R602 1-216-821-11 METAL CHIP 1K 5% 1/16W
R603 1-216-809-11 METAL CHIP 100 5% 1/16W
R604 1-216-809-11 METAL CHIP 100 5% 1/16W
R605 1-216-809-11 METAL CHIP 100 5% 1/16W
R606 1-216-809-11 METAL CHIP 100 5% 1/16W
R607 1-216-809-11 METAL CHIP 100 5% 1/16W
R608 1-216-809-11 METAL CHIP 100 5% 1/16W
R610 1-216-809-11 METAL CHIP 100 5% 1/16W
R611 1-216-809-11 METAL CHIP 100 5% 1/16W
R612 1-216-809-11 METAL CHIP 100 5% 1/16W
R613 1-216-809-11 METAL CHIP 100 5% 1/16W
R614 1-216-809-11 METAL CHIP 100 5% 1/16W
R615 1-216-809-11 METAL CHIP 100 5% 1/16W
R616 1-216-809-11 METAL CHIP 100 5% 1/16W
R617 1-216-809-11 METAL CHIP 100 5% 1/16W
R618 1-216-809-11 METAL CHIP 100 5% 1/16W
