Ref. No. Part No. Description Remark
HCD-DZ280/DZ680/HDZ284/HDZ485
100
C5307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5308 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C5309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5310 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C5311 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5312 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C5313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5314 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C5315 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN5301 1-564-523-11 PLUG, CONNECTOR 8P
< TERMINAL BOARD >
TB5301 1-780-454-11 TERMINAL BOARD (SPEAKER) 4P
(SPEAKER (FRONT R,FRONT L,SUR R,SUR L))
*************************************************************
USB BOARD (DZ280/DZ680)
**********
< CAPACITOR >
C5200 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5200 1-822-423-11 CONNECTOR, USB (A) 7P (USB)
CN5201 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
*************************************************************
MISCELLANEOUS
**************
4 1-827-720-11 WIRE (FLAT TYPE) (11 CORE) (DZ280/DZ680)
4 1-828-955-11 WIRE (FLAT TYPE) (9 CORE) (HDZ284/HDZ485)
0 6 1-834-966-21 CORD, POWER (PX)
0 6 1-834-966-41 POWER-SUPPLY CORD (AEP,UK)
0 6 1-834-978-11 CORD, POWER (CND)
11 1-828-330-11 WIRE (FLAT TYPE) (13 CORE) (DZ680/HDZ485)
0 12 1-569-008-33 ADAPTOR, CONVERSION 2P (PX)
0 13 1-770-019-71 ADAPTOR, CONVERSION PLUG 3P (UK)
60 1-828-353-11 WIRE (FLAT TYPE) (17 CORE)
63 1-828-287-11 WIRE (FLAT TYPE) (5 CORE)
107 1-828-293-11 WIRE (FLAT TYPE) (5 CORE)
109 1-828-286-11 WIRE (FLAT TYPE) (5 CORE)
110 1-828-349-11 WIRE (FLAT TYPE) (17 CORE) (HDZ284/HDZ485)
110 1-828-359-11 WIRE (FLAT TYPE) (19 CORE) (DZ280/DZ680)
111 1-828-347-11 WIRE (FLAT TYPE) (17 CORE) (HDZ284/HDZ485)
111 1-828-357-11 WIRE (FLAT TYPE) (19 CORE) (DZ280/DZ680)
0 157 8-820-321-12 OPTICAL PICK-UP (KHM313CAA/C2RP1)
158 1-828-773-51 WIRE (FLAT TYPE) (24 CORE)
0 F901 1-533-311-12 FUSE, GLASS CYLINDRICAL (DIA. 5) (8A/250V)
(CND)
0 F901 1-576-232-51 FUSE (H.B.C.) (5A/250V) (AEP,UK)
0 F901 1-576-233-51 FUSE (H.B.C.) (6.3A/250V) (PX)
FAN3001 1-787-396-11 D.C. FAN (50 SQUARE)
TU4001 1-693-768-11 TUNER (FM) (ANTENNA) (DZ280/DZ680)
TU4001 1-693-781-11 TUNER (FM) (ANTENNA) (HDZ284/HDZ485)
SPEAKER USB
Ver. 1.1
