HCD-DZ280/DZ680/HDZ284/HDZ485
SECTION 8
ELECTRICAL PARTS LIST
A-1579-632-A FL-JACK BOARD, COMPLETE (DZ280:UK/DZ680)
A-1579-685-A FL-JACK BOARD, COMPLETE (DZ280:AEP)
A-1599-817-A FL-JACK BOARD, COMPLETE (HDZ284/HDZ485)
***********************
< CAPACITOR >
C5000 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C5002 1-126-382-11 ELECT 100uF 20% 16V
C5003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5004 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C5005 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C5006 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5007 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5008 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5009 1-119-943-11 ELECT 47uF 20% 50V
C5010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5011 1-126-157-11 ELECT 10uF 20% 16V
C5012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5020 1-126-157-11 ELECT 10uF 20% 16V
C5021 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5023 1-115-156-11 CERAMIC CHIP 1uF 10V
(EXCEPT DZ280:AEP)
C5024 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(EXCEPT DZ280:AEP)
C5025 1-124-584-00 ELECT 100uF 20% 6.3V
(EXCEPT DZ280:AEP)
C5026 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C5027 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5028 1-124-589-11 ELECT 47uF 20% 16V
C5029 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5030 1-124-584-00 ELECT 100uF 20% 6.3V
C5031 1-126-157-11 ELECT 10uF 20% 16V
C5032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5035 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5036 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5037 1-126-157-11 ELECT 10uF 20% 16V
C5038 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5040 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C5041 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5042 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
(EXCEPT DZ280:AEP)
C5043 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
(EXCEPT DZ280:AEP)
C5044 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(EXCEPT DZ280:AEP)
C5045 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5046 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(EXCEPT DZ280:AEP)
C5050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT DZ280:AEP)
C5051 1-124-584-00 ELECT 100uF 20% 10V
(EXCEPT DZ280:AEP)
C5052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT DZ280:AEP)
C5058 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5059 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5061 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN5000 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
CN5001 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P
< DIODE >
D5000 6-500-848-01 DIODE MC2840-T112-1
D5001 6-500-848-01 DIODE MC2840-T112-1
D5002 6-501-729-01 DIODE MAZ8051GLLS0
D5003 8-719-060-26 LED SLR-325YCT31 (MOVIE)
D5004 8-719-060-26 LED SLR-325YCT31 (MUSIC)
D5005 6-500-525-01 LED SLI-325YCT31W (i-ENHANCER)
(HDZ284/HDZ485)
D5005 6-502-469-01 LED SLI-325URT31 (i-ENHANCER)
(DZ280/DZ680)
D5006 6-501-817-01 DIODE MA2J1110GLS0
D5007 6-500-848-01 DIODE MC2840-T112-1 (EXCEPT DZ280:AEP)
D5008 8-719-058-24 DIODE RB501V-40TE-17 (EXCEPT DZ280:AEP)
D5009 6-500-848-01 DIODE MC2840-T112-1
D5010 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB5000 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5001 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5002 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5003 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5006 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
< IC >
IC5000 6-702-302-01 IC TK11133CSCL-G
IC5001 6-713-497-01 IC HT16515
IC5002 6-600-349-21 IC NJL23H400A (IR)
IC5003 8-759-100-96 IC uPC4558G2
IC5004 8-759-100-96 IC uPC4558G2 (EXCEPT DZ280:AEP)
< JACK >
J5000 1-822-262-11 JACK (AUDIO IN/A.CAL MIC)
