HCD-DZ280/DZ680/HDZ284/HDZ485
HCD-DZ280/DZ680/HDZ284/HDZ485
3737
• Waveforms
– MAIN Board –
 IC1101  (DVDRFIP)
200 mV/DIV, 100 ns/DIV
 IC1101 [Y (R/Cr/Pr)
200 mV/DIV, 20 μs/DIV
 IC1101 [D (B/Cb/Pb)
200 mV/DIV, 20 μs/DIV
 IC1101 [C (Y/G)
500 mV/DIV, 20 μs/DIV
 IC1101 [ (C)
500 mV/DIV, 20 μs/DIV
 IC1101 [[ (Y)
500 mV/DIV, 20 μs/DIV
 IC1101 YD (XTALO)
500 mV/DIV, 20 ns/DIV
 IC503 RE (Xout)
1 V/DIV, 100 ns/DIV
 IC304 RE (CKOUT(O))
1 V/DIV, 20 ns/DIV
 IC304 RG (BCK(O))
1 V/DIV, 50 ns/DIV
RB IC304 RH (LRCK(O))
1 V/DIV, 5 μs/DIV
RT IC304 XB (XOUT(O))
1 V/DIV, 20 ns/DIV
RE IC3051  (3Y)
1 V/DIV, 10 ns/DIV
RG IC3010 SL (XFSOIN)
1 V/DIV, 10 ns/DIV
RH IC3010 RG (XFSOOUT)
1 V/DIV, 10 ns/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
3.5Vp-p
1.6Vp-p 5Vp-p
4.3Vp-p
4Vp-p
3.5Vp-p
27MHz
3.4Vp-p
5MHz
40.7nsec
163nsec
10.4μsec
24.576MHz
49.1MHz
49.1MHz
49.1MHz
650mVp-p
H
3.5Vp-p
4Vp-p
– IO-SCART Board (DZ280/DZ680) – – IO-COMPONENT Board (HDZ284/HDZ485) –
 IC4000  (Cin)
500 mV/DIV, 20 μs/DIV
 IC4000  (Yin)
500 mV/DIV, 20 μs/DIV
 IC4000  (CVin)
500 mV/DIV, 20 μs/DIV
 IC4000 RT (Cbin)
200 mV/DIV, 20 μs/DIV
 IC4000 RG (Crin)
500 mV/DIV, 20 μs/DIV
 IC400 XE (CVBSout)
1 V/DIV, 20 μs/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
H
H
2.6Vp-p
 IC4002  (Cin)
500 mV/DIV, 20 μs/DIV
 IC4002  (Yin)
500 mV/DIV, 20 μs/DIV
 IC4002  (CYin)
500 mV//DIV, 20 μs/DIV
 IC4002 RT (Cb in)
200 mV/DIV, 20 μs/DIV
 IC4002 RG (Cr in)
200 mV/DIV, 20 μs/DIV
 IC4002 X (CY OUT)
1 V/DIV, 20 μs/DIV
 IC4002 RL (Cb OUT)
500 mV/DIV, 20 μs/DIV
 IC4002 RI (Cr OUT)
500 mV/DIV, 20 μs/DIV
 IC4002 XE (CVBS OUT)
1 V/DIV, 20 μs/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
H
2Vp-p
1Vp-p
H
2Vp-p
H
H
H
2.6Vp-p
