Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ280/DZ680/HDZ284/HDZ485
86
R4089 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R4093 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R4094 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4095 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4103 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4104 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4108 1-216-864-11 SHORT CHIP 0
R4110 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4111 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4112 1-216-864-11 SHORT CHIP 0
R4114 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4115 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4116 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4124 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4125 1-216-864-11 SHORT CHIP 0
R4128 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4131 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4133 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4146 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4147 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4148 1-216-864-11 SHORT CHIP 0
R4149 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4150 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4156 1-216-864-11 SHORT CHIP 0
R4157 1-216-864-11 SHORT CHIP 0
R4158 1-216-864-11 SHORT CHIP 0
R4159 1-216-864-11 SHORT CHIP 0
R4164 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ680)
R4166 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1579-634-A KEY-SW BOARD, COMPLETE
***********************
< CAPACITOR >
C5111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5112 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN5101 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
< RESISTOR >
R5113 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5114 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5115 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5116 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5123 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5124 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5125 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5126 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5127 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5128 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S5100 1-762-875-21 SWITCH, KEYBOARD (Z)
S5101 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S5102 1-762-875-21 SWITCH, KEYBOARD (X)
S5103 1-762-875-21 SWITCH, KEYBOARD (x)
S5109 1-762-875-21 SWITCH, KEYBOARD (N)
S5111 1-786-289-11 SWITCH, DETECTION
(OPERATION DIAL, >/.)
S5113 1-480-136-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
*************************************************************
9 A-1579-689-A MAIN BOARD, COMPLETE (for SERVICE)
(DZ280:AEP)
9 A-1579-697-A MAIN BOARD, COMPLETE (for SERVICE)
(DZ280:UK)
9 A-1579-736-A MAIN BOARD, COMPLETE (for SERVICE)
(HDZ284)
9 A-1579-796-A MAIN BOARD, COMPLETE (for SERVICE) (DZ680)
9 A-1602-817-A MAIN BOARD, COMPLETE (for SERVICE)
(HDZ485)
*********************
< CAPACITOR >
C303 1-100-742-11 CERAMIC CHIP 2.2uF 20% 10V
C304 1-126-923-11 ELECT 220uF 20% 10V
(EXCEPT DZ280)
C305 1-100-742-11 CERAMIC CHIP 2.2uF 20% 10V
C308 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C310 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C311 1-126-964-11 ELECT 10uF 20% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-923-11 ELECT 220uF 20% 10V
(EXCEPT DZ280)
C316 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT DZ280)
C317 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT DZ280)
C318 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
(EXCEPT DZ280)
C319 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT DZ280)
C320 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT DZ280)
C321 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT DZ280)
C323 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT DZ280)
C325 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT DZ280)
C326 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
(EXCEPT DZ280)
C327 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
(EXCEPT DZ280)
C329 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT DZ280)
C333 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C334 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C451 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C452 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C453 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C455 1-126-965-11 ELECT 22uF 20% 50V
C456 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C457 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C461 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C462 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C463 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C464 1-126-947-11 ELECT 47uF 20% 35V
C465 1-104-658-11 ELECT 100uF 20% 10V
