Sony HCD-DZ770W - Printed Wiring Board - I;O Board (Side A)

4848
HCD-DZ770W
HCD-DZ770W
6-27. PRINTED WIRING BOARD – I/O BOARD (SIDE A) –
• Semiconductor
Location
Ref. No. Location
IC201 B-6
IC203 B-4
IC204 B-5
IC601 C-3
IC602 C-3
Q601 C-2
Q602 C-2
Q603 C-4
Q604 C-4
Q605 C-2
• See page 21 for Circuit Boards Location.
:Uses unleaded solder.
IC201
IC204
IC203
IC602
IC601
E
E
E
EE
12
A
B
C
D
3456
