6-7. PRINTED WIRING BOARD – DMB10 BOARD (SIDE A) –
• See page 21 for Circuit Boards Location.
• Semiconductor
Location
Ref. No.
Location
D1001 C-5
D3501 A-4
D3502 A-4
IC101 D-3
IC102 C-3
IC103 C-4
IC104 C-4
IC106 C-5
IC201 D-5
Q103 C-2
✩ IC103 is a written in and settled EEPROM. Supply with
a single article has not been carried out. In case you
exchange by DMB10 board, please put on IC103
currently used with the model again.
IC102
IC101
IC103
IC106
IC104
IC201
I
I/O
BOARD
CN201
(Page 49)
J
D
MAIN
BOARD
CN505
(Page 34)
MS-203
BOARD
CN001
(Page 52)
B
MAIN
BOARD
CNP506
(Page 35)
A
MAIN
BOARD
CN504
(Page 34)
for
CHECK
E
1
5
10
11
R1111
C223
R228
R227
C226
C225
R243
CN202
6
7
R1545
OPTICAL
PICK-UP
BLOCK
(KHM-310CAA/
C2NP)
SPINDLE
MOTOR,
SLED
MOTOR
12
A
B
C
D
E
3456
