9
HCD-DZ770W
3-2. CASE, FRONT PANEL ASSY
Note: Follow the disassembly procedure in the numerical order given.
DVD lid
1
The lever is moved in the direction
of the arrow with the thin rod.
2
3
DVD lid assy
4
screw (CASE3 TP2)
5
screw
(CASE3 TP2)
6
five screws (+BVTP 3
×
8)
qd
floating
screw (+PTPWH M2.6)
7
case
qg
front panel assy
8
three screws (+BVTP 3
×
8)
qs
w
ire (flat type)
19core(CN509)
qa
connector
(CN309)
qf
IPOD board
0
claw
9
