Sony HCD-DZ770W - Printed Wiring Boards - AUDIO IN;OUT Section

4646
HCD-DZ770W
HCD-DZ770W
6-25. PRINTED WIRING BOARDS – AUDIO IN/OUT SECTION –
• See page 21 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D821 B-2
D822 B-2
IC605 B-5
Q807 B-2
Q808 B-3
:Uses unleaded solder.
IC605
E
E
51
MAIN
BOARD
CN309
(Page 35)
H
PHONES
J801
I/O
BOARD
CN602
(Page 49)
G
AUDIO IN
(21)
21
12
A
B
C
D
3456
