HCD-DZ770W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
L601 1-469-525-91 INDUCTOR 10uH
L602 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q601 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
(EXCEPT KR)
Q601 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR (KR)
Q602 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
(EXCEPT KR)
Q602 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR (KR)
Q603 8-729-901-00 TRANSISTOR DTC124EKA-T146 (KR)
Q603 8-729-027-52 TRANSISTOR RT1N241C-TP-1
(EXCEPT KR)
Q604 8-729-901-00 TRANSISTOR DTC124EKA-T146 (KR)
Q604 8-729-027-52 TRANSISTOR RT1N241C-TP-1
(EXCEPT KR)
Q605 8-729-027-23 TRANSISTOR DTA114EKA-T146 (KR)
Q605 8-729-027-23 TRANSISTOR RT1P141C-TP-1
(EXCEPT KR)
< RESISTOR >
R102 1-216-864-11 SHORT CHIP 0
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R114 1-216-864-11 SHORT CHIP 0
R115 1-216-845-11 METAL CHIP 100K 5% 1/10W
R116 1-216-845-11 METAL CHIP 100K 5% 1/10W
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R201 1-218-285-11 METAL CHIP 75 5% 1/10W
R202 1-218-285-11 METAL CHIP 75 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R205 1-216-864-11 SHORT CHIP 0
R206 1-216-864-11 SHORT CHIP 0
R207 1-216-864-11 SHORT CHIP 0
R209 1-216-864-11 SHORT CHIP 0
R226 1-216-864-11 SHORT CHIP 0
R228 1-216-833-11 METAL CHIP 10K 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R241 1-218-285-11 METAL CHIP 75 5% 1/10W
R606 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R607 1-216-841-11 METAL CHIP 47K 5% 1/10W
R608 1-216-841-11 METAL CHIP 47K 5% 1/10W
R609 1-216-817-11 METAL CHIP 470 5% 1/10W
R610 1-216-817-11 METAL CHIP 470 5% 1/10W
R611 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R612 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R613 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R614 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R615 1-216-841-11 METAL CHIP 47K 5% 1/10W
R616 1-216-841-11 METAL CHIP 47K 5% 1/10W
R617 1-216-821-11 METAL CHIP 1K 5% 1/10W
R618 1-216-833-11 METAL CHIP 10K 5% 1/10W
R619 1-216-821-11 METAL CHIP 1K 5% 1/10W
R620 1-216-833-11 METAL CHIP 10K 5% 1/10W
R622 1-216-821-11 METAL CHIP 1K 5% 1/10W
R623 1-216-841-11 METAL CHIP 47K 5% 1/10W
R624 1-216-841-11 METAL CHIP 47K 5% 1/10W
R625 1-216-841-11 METAL CHIP 47K 5% 1/10W
R626 1-216-841-11 METAL CHIP 47K 5% 1/10W
R627 1-216-841-11 METAL CHIP 47K 5% 1/10W
R628 1-216-841-11 METAL CHIP 47K 5% 1/10W
R629 1-216-841-11 METAL CHIP 47K 5% 1/10W
R630 1-216-841-11 METAL CHIP 47K 5% 1/10W
R631 1-216-841-11 METAL CHIP 47K 5% 1/10W
R632 1-216-841-11 METAL CHIP 47K 5% 1/10W
R635 1-216-841-11 METAL CHIP 47K 5% 1/10W
R636 1-216-864-11 SHORT CHIP 0
R637 1-216-864-11 SHORT CHIP 0
R638 1-216-821-11 METAL CHIP 1K 5% 1/10W
R639 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R644 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R645 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R648 1-216-833-11 METAL CHIP 10K 5% 1/10W
R649 1-216-833-11 METAL CHIP 10K 5% 1/10W
R650 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R651 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R654 1-216-841-11 METAL CHIP 47K 5% 1/10W
R655 1-216-833-11 METAL CHIP 10K 5% 1/10W
R656 1-216-833-11 METAL CHIP 10K 5% 1/10W
R659 1-216-809-11 METAL CHIP 100 5% 1/10W
R663 1-216-845-11 METAL CHIP 100K 5% 1/10W
R664 1-216-845-11 METAL CHIP 100K 5% 1/10W
R674 1-216-833-11 METAL CHIP 10K 5% 1/10W
R675 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
IPOD BOARD
**********
< CAPACITOR >
C636 1-216-864-11 SHORT CHIP 0
C637 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C638 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C639 1-126-964-11 ELECT 10uF 20% 50V
C640 1-126-964-11 ELECT 10uF 20% 50V
C641 1-126-933-11 ELECT 100uF 20% 16V
C642 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C643 1-126-933-11 ELECT 100uF 20% 16V
C646 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< IC >
IC605 8-759-649-89 IC MC4558CD
< JACK >
J603 1-566-822-51 JACK (AUDIO IN)
< RESISTOR >
R605 1-216-817-11 METAL CHIP 470 5% 1/10W
R621 1-216-864-11 SHORT CHIP 0
R642 1-216-864-11 SHORT CHIP 0
R643 1-216-864-11 SHORT CHIP 0
R665 1-216-817-11 METAL CHIP 470 5% 1/10W
