Sony HCD-DZ770W - Printed Wiring Board - TX Board

5353
HCD-DZ770W
HCD-DZ770W
6-33. PRINTED WIRING BOARD – TX BOARD –
• See page 21 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D800 B-2
IC800 B-7
IC801 B-2
IC802 B-3
IC803 B-2
IC804 B-3
IC805 B-2
Q801 A-2
:Uses unleaded solder.
IC801
IC803
IC802
IC804
IC805
IC800
V
MAIN BOARD
CN512
(Page 34)
W
MAIN BOARD
CN902
(Page 35)
DIR-T1
12
A
B
C
3456 7
