HCD-DZ770W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C212 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C217 1-126-204-11 ELECT CHIP 47uF 20% 16V
C218 1-124-779-00 ELECT CHIP 10uF 20% 16V
C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C220 1-124-779-00 ELECT CHIP 10uF 20% 16V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C223 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C225 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C226 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C233 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C402 1-126-204-11 ELECT CHIP 47uF 20% 16V
C403 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C4501 1-117-370-11 CERAMIC CHIP 10uF 10V
C4502 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN101 1-815-763-11 CONNECTOR, FFC/FPC 24P
* CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN106 1-784-370-21 CONNECTOR, FFC/FPC 11P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN202 1-784-365-21 CONNECTOR, FFC/FPC 5P
CN301 1-793-989-21 CONNECTOR, FFC/FPC 13P
CN401 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN4501 1-784-370-21 CONNECTOR, FFC/FPC 11P
< DIODE >
D1001 8-719-058-24 DIODE RB501V-40TE-17
D3501 8-719-988-61 DIODE 1SS355TE-17
D3502 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB112 1-414-226-21 INDUCTOR, FERRITE BEAD
FB113 1-414-226-21 INDUCTOR, FERRITE BEAD
FB114 1-414-226-21 INDUCTOR, FERRITE BEAD
FB115 1-414-226-21 INDUCTOR, FERRITE BEAD
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FILTER >
FL101 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL104 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL105 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL106 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL107 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL108 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL401 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL402 1-233-893-21 FILTER, CHIP EMI
FL403 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL4501 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 6-805-705-01 IC S29JL032H70-OED1-0503CE (E3, AUS)
IC101 6-805-706-01 IC S29JL032H70-OED1-0503GA (SP, KR)
IC102 6-706-727-01 IC CXD9804R
✩ IC103 not supplied IC BR24L64F-WE2
IC104 6-706-390-11 IC HY57V641620HGTP-HDR
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 6-708-153-01 IC PQ018EN01ZPH
IC107 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC4501 8-759-573-97 IC SN74LVC541APWR
IC4502 8-759-649-50 IC SN74AHC1GU04DCKR
< TRANSISTOR >
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR RT1N241C-TP-1
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R126 1-216-864-11 SHORT CHIP 0
R133 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R134 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R135 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R138 1-216-845-11 METAL CHIP 100K 5% 1/10W
R141 1-218-916-11 METAL CHIP 750K 5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R143 1-216-809-11 METAL CHIP 100 5% 1/10W
R144 1-216-864-11 SHORT CHIP 0
R151 1-216-805-11 METAL CHIP 47 5% 1/10W
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-805-11 METAL CHIP 47 5% 1/10W
DMB10
✩ IC103 is a written in and settled EEPROM. Supply with a
single article has not been carried out. In case you exchange
by DMB10 board, please put on IC103 currently used with
the model again.
