86
HCD-DZ770W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R933 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-216-833-11 METAL CHIP 10K 5% 1/10W
R938 1-216-821-11 METAL CHIP 1K 5% 1/10W
R939 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R941 1-216-864-11 SHORT CHIP 0
R943 1-216-864-11 SHORT CHIP 0
R946 1-216-811-11 METAL CHIP 150 5% 1/10W
R948 1-216-833-11 METAL CHIP 10K 5% 1/10W
R949 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R952 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R953 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R954 1-216-837-11 METAL CHIP 22K 5% 1/10W
R955 1-216-817-11 METAL CHIP 470 5% 1/10W
R956 1-216-821-11 METAL CHIP 1K 5% 1/10W
R957 1-216-841-11 METAL CHIP 47K 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R965 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB502 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB503 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB504 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB505 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB506 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB507 1-233-576-11 RES, CHIP NETWORK 100 (3216)
< TRANSFORMER >
0 T901 1-443-651-11 TRANSFORMER, CONVERTER
0 T902 1-443-650-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0 TH901 1-805-842-21 THERMISTOR, NTC 6.0
< VARISTOR >
0 VDR901 1-805-482-11 VARISTOR
< VIBRATOR >
X450 1-795-660-21 QUARTZ CRYSTAL UNIT 49.152MHz
X500 1-795-843-11 VIBRATOR, CRYSTAL 12.288MHz
X501 1-813-325-11 VIBRATOR, CRYSTAL 13.9MHz
X502 1-795-058-21 VIBRATOR, CERAMIC 5MHz
************************************************************
MS-203 BOARD
************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION
MAIN MS-203 STBY
************************************************************
STBY BOARD
**********
< CONNECTOR >
CN804 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (4/1)
************************************************************
A-1110-573-A TX BOARD, COMPLETE (KR)
A-1116-283-A TX BOARD, COMPLETE (EXCEPT KR)
******************
< CAPACITOR >
C800 1-128-950-21 ELECT 1000uF 20% 16V
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C805 1-126-933-11 ELECT 100uF 20% 16V
C806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C812 1-104-658-91 ELECT 100uF 20% 10V
C813 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C814 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C815 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C816 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C817 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C819 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C820 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C821 1-104-658-91 ELECT 100uF 20% 10V
C822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C823 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C825 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C826 1-104-658-91 ELECT 100uF 20% 10V
C827 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C828 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C829 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C830 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C831 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C832 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C833 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C834 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C835 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C836 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C837 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C838 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C839 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C840 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C841 1-126-961-11 ELECT 2.2uF 20% 50V
C842 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C844 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
