Sony HCD-DZ830W - 3 Disassembly; Disassembly Flow

16
HCD-DZ830W/DZ850KW
SECTION 3
DISASSEMBLY
3-1. DISASSEMBLY FLOW
•This set can be disassembled in the order shown below.
• Abbreviation
E32 : 110 – 240V AC area in E model
MX : Mexican model
3-3. FL BOARD
(Page 18)
3-4. JACK BOARD,
P-SW BOARD
(Page 19)
3-5. FRONT PANEL,
ORNAMENT
(Page 19)
3-14. DVD MECHANISM DECK
(CDM85-DVBU102)
(Page 25)
3-15. TRAY
(Page 25)
3-16. BELT,
MS-203 BOARD
(Page 26)
3-17. OPTICAL PICK-UP
(KHM-313CAA)
(Page 27)
3-13. MAIN BOARD,
DSP BOARD
(Page 24)
3-7. DMPORT BOARD
(EXCEPT E32, MX MODELS)
(Page 20)
3-8. DIAT-TX BOARD
(Page 21)
3-11. IO-SCART BOARD
(DZ830W)
(Page 22)
3-10. IO-S-OUT BOARD
(DZ850KW)
(Page 22)
3-12. SPEAKER BOARD,
D.C. FAN
(Page 23)
3-9. POWER BOARD
(Page 21)
3-6. TUNER (FM/AM)
(Page 20)
3-2. CASE (DS),
FRONT PANEL ASSY
(Page 17)
SET
Ver. 1.1
