20
HCD-DZ830W/DZ850KW
3-6. TUNER (FM/AM)
3-7. DMPORT BOARD (EXCEPT E32, MX MODELS)
•Abbreviation
E32 : 110 – 240V AC area in E model
MX : Mexican model
2
wire (flat type) 9core (DZ850KW)
wire (flat type) 11core (DZ830W)
1
two
screws
(+BVTT
2.6
×
6
)
3
tuner (FM/AM)
1
screw
(+BVTP
3
×
8
)
5
DMPORT board
2
claw
3
wire (flat type)
9core (CN201)
4
connector
3p (CN203)
Ver. 1.1
