HCD-DZ830W/DZ850KW
3-5. FRONT PANEL, ORNAMENT
3-4. JACK BOARD, P-SW BOARD
Route the harness as shown below.
JACK board JACK board
(NG)(OK)
1
knob (vol)
2
nut
qa
JACK board
4
button (base)
5
wire (flat type)
13core (CN806)
8
Remove the
solderings.
9
harness
3
four
screws
(+BVTP
2.6
×
10
)
6
screw
(+BVTP
2.6
×
10
)
7
button (base)
q;
P-
SW board
JACK board JACK board
Route the harness as shown below.
(NG)(OK)
2
six
claws
6
ornament
3
front panel
1
screw
(+BVTP
2.6
×
10
)
4
six
claws
5
button (cap)
