17
HCD-DZ830W/DZ850KW
3-2. CASE (DS), FRONT PANEL ASSY
Note: Follow the disassembly procedure in the numerical order given.
qf
two
screws
(+BVTP
2.6
×
10
)
q;
w
ire (flat type)
21core (CN502)
2
The lever is moved in the direction
of the arrow with the thin rod.
1
seal
3
4
loading panel
5
two screws
(CASE3 TP2)
8
case (DS)
qj
front panel assy
qd
four screws
(+BV 3
×
6)
qs
connector 4P (CN3001) (DZ830W)
qh
three claws
qg
three
claws
6
two screws
(CASE3 TP2)
7
five screws
(+BVTP 3
×
8)
9
unweaved
cloth
rib
notch
harness
rib
lead pin
Route the harness as shown below.
qa
connector 5P (CN302) (DZ850KW)
connector 4P (CN302) (DZ830W)
