22
HCD-DZ830W/DZ850KW
3-11. IO-SCART BOARD (DZ830W)
3-10. IO-S-OUT BOARD (DZ850KW)
•Abbreviation
E32 : 110 – 240V AC area in E model
MX : Mexican model
9
six
screws
(+BVTP
3
×
8
)
q;
screw
(+BV
3
×
6
)
qa
IO-S-OUT board
4
wire (flat type) 21core (CN311) (E32, MX)
wire (flat type) 25core (CN306) (except E32, MX
5
wire (flat type)
5core (CN307)
7
wire (flat type)
9core (CN305)
8
wire (flat type)
9core (CN301)
(except E32, MX)
6
connector
5p (CN302)
3
wire (flat type)
11core (CN304)
1
two screws
(+BV
3
×
6
)
2
bracket
(DIAT DS)
9
six
screws
(+BVTP
3
×
8
)
q;
screw
(+BV
3
×
6
)
qa
IO-SCART board
4
w
ire (flat type) 25core
(CN306)
5
wire (flat type)
5core (CN307)
7
wire (flat type)
11core (CN305)
6
connector
4p (CN302)
3
wire (flat type)
13core (CN304)
1
two screws
(+BV
3
×
6
)
2
bracket
(DIAT DS)
8
wire (flat type)
9core (CN301)
Ver. 1.1
