94
HCD-DZ830W/DZ850KW
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. ., uPA. . : µPA. .,
uPB. . : µPB. ., uPC. . : µPC. .,
uPD. . : µPD. .
•Abbreviation
AUS:Australian model
E3 : 220 – 240V AC area in E model
E32 : 110 – 240V AC area in E model
KR : Korean model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
A-1231-253-A DIAT-TX BOARD, COMPLETE
***********************
< CAPACITOR >
C1801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1804 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1812 1-126-964-11 ELECT 10uF 20% 50V
C1816 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1819 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C1820 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C1821 1-126-964-11 ELECT 10uF 20% 50V
C1822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1823 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1825 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1826 1-126-964-11 ELECT 10uF 20% 50V
C1827 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1828 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1829 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1830 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1831 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1832 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C1833 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1834 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1835 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C1836 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1837 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1838 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1839 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1840 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1841 1-126-961-11 ELECT 2.2uF 20% 50V
C1842 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1844 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1845 1-126-964-11 ELECT 10uF 20% 50V
C1846 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1848 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1850 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1851 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1860 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1861 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1864 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1865 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1866 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1867 1-126-933-11 ELECT 100uF 20% 16V
C1868 1-126-933-11 ELECT 100uF 20% 16V
C1869 1-126-933-11 ELECT 100uF 20% 16V
C1870 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN1801 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< FERRITE BEAD >
FB1801 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1802 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1803 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1804 1-414-234-22 INDUCTOR, FERRITE BEAD
< IC >
IC1800 6-700-792-01 IC NJM78M09DL1A (TE1)
IC1801 6-704-261-01 IC TK11225CMCL-G
IC1802 8-759-548-99 IC SN74LV08APWR
IC1803 8-759-549-01 IC SN74LV125APWR
IC1804 8-752-425-05 IC CXD4016R
IC1805 8-759-684-21 IC AD8057ARTZ-REEL7
< JACK >
J1801 1-818-634-11 JACK, PIN 1P (DIR-T1)
< COIL >
L1806 1-469-525-91 INDUCTOR 10uH
L1807 1-469-525-91 INDUCTOR 10uH
L1808 1-469-525-91 INDUCTOR 10uH
L1809 1-469-525-91 INDUCTOR 10uH
L1810 1-469-525-91 INDUCTOR 10uH
L1811 1-400-305-11 INDUCTOR 47uH
L1812 1-414-741-11 INDUCTOR 10uH
< TRANSISTOR >
Q1801 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R1802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1803 1-216-809-11 METAL CHIP 100 5% 1/10W
DIAT-TX
The components identified by mark 9 contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
MX : Mexican model
SP : Singapore model
TW : Taiwan model
Ver. 1.1
