Sony HCD-DZ830W - FL Board

18
HCD-DZ830W/DZ850KW
3-3. FL BOARD
PRECAUTION DURING THE RETAINER (DS) INSTALLATION
(2) Route the harness as shown below. (3) Route the harness as shown below.
(1) Assemble seven claws securely.
4 shield plate (FR)
shield plate (FR)
front panel
8 FL board
FL board
JACK
board
CN806
CN805
3 five screws
(+BVTP 2.6
× 10)
5 two screws
(+BVTP 2.6
× 10)
1 two
rivets
6 wire (flat type)
13core (CN805)
wire (flat type) 13core
7 wire (flat type)
21core (CN801)
2 retainer (DS)
retainer (DS)
harness
rivet rivet
hole
retainer (DS)
harness
wire (flat type)
groove
groove
retainer (DS)
hole
Route the wire
(flat type) 13core
as shown in the figure.
