95
HCD-DZ830W/DZ850KW
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R1804 1-216-809-11 METAL CHIP 100 5% 1/10W
R1805 1-216-809-11 METAL CHIP 100 5% 1/10W
R1806 1-216-809-11 METAL CHIP 100 5% 1/10W
R1807 1-216-809-11 METAL CHIP 100 5% 1/10W
R1808 1-216-809-11 METAL CHIP 100 5% 1/10W
R1809 1-216-809-11 METAL CHIP 100 5% 1/10W
R1810 1-216-809-11 METAL CHIP 100 5% 1/10W
R1811 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1812 1-216-815-11 METAL CHIP 330 5% 1/10W
R1813 1-216-813-11 METAL CHIP 220 5% 1/10W
R1814 1-216-809-11 METAL CHIP 100 5% 1/10W
R1815 1-216-815-11 METAL CHIP 330 5% 1/10W
R1816 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1818 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1819 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1820 1-216-813-11 METAL CHIP 220 5% 1/10W
R1821 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1822 1-216-811-11 METAL CHIP 150 5% 1/10W
R1823 1-216-813-11 METAL CHIP 220 5% 1/10W
R1824 1-216-817-11 METAL CHIP 470 5% 1/10W
R1825 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1826 1-216-811-11 METAL CHIP 150 5% 1/10W
R1827 1-216-811-11 METAL CHIP 150 5% 1/10W
R1829 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1830 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1831 1-220-397-11 METAL CHIP 4.7M 5% 1/10W
R1832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1833 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1834 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1837 1-216-803-11 METAL CHIP 33 5% 1/10W
R1838 1-216-809-11 METAL CHIP 100 5% 1/10W
R1839 1-216-809-11 METAL CHIP 100 5% 1/10W
R1840 1-216-809-11 METAL CHIP 100 5% 1/10W
R1841 1-216-809-11 METAL CHIP 100 5% 1/10W
R1842 1-216-809-11 METAL CHIP 100 5% 1/10W
R1843 1-216-809-11 METAL CHIP 100 5% 1/10W
R1844 1-216-809-11 METAL CHIP 100 5% 1/10W
< VARIABLE RESISTOR >
RV1801 1-223-582-11 RES, ADJ, CARBON 470
< VIBRATOR >
X1801 1-795-692-11 QUARTZ CRYSTAL UNIT (24.576MHz)
************************************************************
A-1218-025-A DMPORT BOARD, COMPLETE
(EXCEPT E32, MX)
************************
< CAPACITOR >
C210 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C212 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C213 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C220 1-128-995-21 ELECT CHIP 100uF 20% 10V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C223 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C229 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C230 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C231 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C232 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C233 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C234 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C235 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C236 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C237 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C238 1-126-395-11 ELECT CHIP 22uF 20% 16V
C239 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C240 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C241 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN201 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN203 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
CN204 1-817-615-21 CONNECTOR BOARD TO BOARD 18P
(DMPORT)
< IC >
IC201 6-705-308-01 IC SI-3010KM-TL
IC202 8-759-710-97 IC NJM4565M-D
< COIL >
L200 1-469-525-91 INDUCTOR 10uH
< RESISTOR >
R203 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R208 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R214 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R215 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R221 1-216-821-11 METAL CHIP 1K 5% 1/10W
R222 1-216-840-11 METAL CHIP 39K 5% 1/10W
R223 1-216-833-11 METAL CHIP 10K 5% 1/10W
R224 1-216-864-11 SHORT CHIP 0
R225 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R227 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R228 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R229 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R230 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R231 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R232 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R237 1-216-864-11 SHORT CHIP 0
R238 1-216-864-11 SHORT CHIP 0
R239 1-216-864-11 SHORT CHIP 0
R240 1-216-809-11 METAL CHIP 100 5% 1/10W
R241 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
A-1267-787-A DSP BOARD, COMPLETE
*******************
< CAPACITOR >
C2 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
DIAT-TX DMPORT DSP
Ver. 1.1
