Sony HCD-DZ830W - Page 73

73
HCD-DZ830W/DZ850KW
– IO-SCART Board –
30
1
2
3
29
28
CV OUT
VCC1
6CV IN
5MUTE1
7SEL (CV/MIX)
13PB/B IN
15PR/R IN
14MUTE2
16VCC2
11PY/G IN
12GND
8Y IN
10SEL (BIAS/CLAMP)
4C IN
S1
S2
CV OUT SAG
GND
BIAS
6dB
75Ω
32 C OUT
75Ω
31 S-DC OUT
6MHz
LPF
27
26
Y OUT
Y OUT SAG
75Ω
6MHz
LPF
6MHz
LPF
S-DC OUT
S1/S2
+
25 GND
24
23
PY/G OUT
PY/G OUT SAG
75Ω
12MHz
LPF
22 GND
21
20
PB/B OUT
PB/B OUT SAG
75Ω
12MHz
LPF
19 GND
18
17
PR/R OUT
PR/R OUT SAG
75Ω
12MHz
LPF
CLAMP
6dB
CLAMP
6dB
6dB
9BIAS
BIAS
BIAS
6dB
BIAS
6dB
CLAMP
BIAS
MUTE1
MUTE2
H
L
L
H
IC201, IC230 BH7868FS-E2
IC303, IC304 MC14052BDR2
