HCD-DZ830W/DZ850KW
Pin No. Pin Name I/O Description
94 KEY2 I Key input 2 input
95 KEY1 I Key input 1 input
96 AVSS — Ground terminal
97 KEY0 I Key input 0 input
98 Vref — Reference voltage (BUP+3.3V)
99 AVCC — Power supply (BUP+3.3V)
100 DIR_HDOUT I DIR data input
