HCD-DZ830W/DZ850KW
Pin No. Pin Name I/O Description
68 G O Not used (Open)
69 AVSS — Ground terminal (analog system) (for D/A converter)
70 B O Not used (Open)
71 R O Not used (Open)
72 SPDIF I SPDIF digital audio signal input from the servo DSP
73 AD3 I Audio serial data input from the servo DSP
74 to 76 AD2 to AD0 I Not used (Fixed to “L”)
77 ACK I Master clock signal input from the servo DSP
78 ABCK I Bit clock signal input from the servo DSP
79 ALRCK I L/R sampling clock signal input from the servo DSP
80 DVDD18 — Power supply terminal (+1.8V) (for digital core)
