Sony HCD-EC79 - Base Unit Disassembly; OP Base Assy (KSM-213 D) Disassembly

HCD-EC69/EC79/EC99
12
3-8. BASE UNIT
3-9. OP BASE ASSY (KSM-213D)
 insulator
 insulator
 base unit
 insulator
 insulator
 two springs
(insulator)
 two screws (PTPWHM2.6)
 two screws (PTPWHM2.6)

 two springs (insulator)
CD mechanism block
(bottom view)
 flexible flat cable (16 core)
(CD board: CN301, optical pick-up)
 OP base assy
(KSM-213D)

CD board

Remove the four solders.
